Digital Floor Series

Digital Floor Series

LEDs on the wall and floor vividly show the landscape and a camera is capturing the scene. LEDs on the wall and floor vividly show the landscape and a camera is capturing the scene.
* All images in this web page are for illustrative purposes only.

Excellent Usability

Surface safety when installing the screen on the floor IP65 protective slip-resistant mat and reflection-reducing surfaces and high visual performance with high contrast LED for uniform visual performance in black are considered. New mask with diffusing powder has been applied for reducing the color shifting and refracting the light to various directions as considering its usage for XR Stage.
LFCG was developed with a matte anti-slip and anti-reflective surface with IP65 protection. LFCG was developed with a matte anti-slip and anti-reflective surface with IP65 protection.
* As the surface is made of polycarbonate, it may be susceptible to scratches (especially against metal).

Easy Installation and Maintenance

Its simple product structure allows for easy installation and quick maintenance. You can quickly deploy and connect the cabinets with the foot support system without any tools. A simple flush control mechanism design is applied to keep the height level regardless of floor type. In addition, magnets attached to the LED module allow for easy maintenance, and hot-swapping* is able during the display operation.
It is easy to install LFCG by simply fixing the cabinet with the footer, and the magnets attached to the LED module allow for easy maintenance with the screen on. It is easy to install LFCG by simply fixing the cabinet with the footer, and the magnets attached to the LED module allow for easy maintenance with the screen on.
* Hot Swapping : Swap module on-site during screen’s on the operation.
Physical Parameters
  • Pixel Configuration
    Single SMD
    Pixel Pitch (mm)
    3.91
  • Module Resolution (W × H)
    64 × 64
    Module Dimensions (W × H, mm)
    250 × 250
  • Weight per Module (kg)
    0.90
    No. of Modules per Cabinet (W × H)
    2 × 2
  • Cabinet Resolution (W × H)
    128 × 128
    Cabinet Dimensions (W × H × D, mm)
    500 × 500 × 83.3
  • Cabinet Surface Area (m²)
    0.250
    Weight per Cabinet (kg/unit)
    11.5
  • Weight per Square Meter (kg/m²)
    46
    Physical Pixel Density (pixels/m²)
    65,536
  • Flatness of Cabinet (mm)
    ±0.3
    Cabinet Material
    Die Casting Aluminum
  • Service Access
    Front
OPTICAL SPECIFICATIONS
  • Max. Brightness (After Calibration, nit)
    1,500
    Color Temperature (K)
    3,500-9,000
  • Visual Viewing Angle (Horizontal)
    160
    Visual Viewing Angle (Vertical)
    160
  • Brightness Uniformity
    0.97
    Color Uniformity
    ±0.003Cx,Cy
  • Contrast Ratio
    5,000:1
    Processing Depth (bit)
    15
ELECTRICAL SPECIFICATIONS
  • Power Consumption (W/Cabinet, Max.)
    165
    Power Consumption (W/Cabinet, Avg.)
    55
  • Power Consumption (W/m², Max.)
    660
    Heat Dissipation (BTU/h/Cabinet, Max.)
    563
  • Heat Dissipation (BTU/h/Cabinet, Avg.)
    187
    Power Supply (V)
    100 to 240
  • Frame Rate (Hz)
    50 / 60
    Refresh Rate (Hz)
    3,840
OPERATION SPECIFICATIONS
  • Lifetime (Half brightness)
    100,000
    Operating Temperature (°C)
    -10° to +45°
  • Operating Humidity
    10 ~ 80%RH
    IP Rating Front
    IP65
  • IP Rating Rear
    IP65
Standard
  • Certification
    CE, FCC, ETL, EMC Class A
Environment
  • Environment
    RoHS, REACH
Controller
  • LFCG039-EN
    LCIN010
    LFCG039-RN
    CVCA
Series
  • Series
    LFCG
  • Dimension
    • LFCG039-GN-v1.0.dwg
    • LFCG039-GN-v1.0.pdf
  • Datasheet
    • LFCG Series_Datasheet(low)_LG LED Signage_241004.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
