55EJ5E-B component-copyModelName
Flat OLED Signage

Key Features

Choose your Size

Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

Flat OLED Signage
Contact Us
Close
Panel
  • Screen Size
    55"
    Native Resolution
    1,920 x 1,080 (FHD)
  • Brightness (APL25%, Typ., cd/m²)
    400
    Brightness (APL100%, Typ., cd/m²)
    150
Connectivity
  • Input
    HDMI, DP, USB 2.0 (2)
    Output
    DP, Audio
  • External Control
    RS232C In/out, RJ45 (LAN) In/out, IR In
Physical Specification
  • Bezel Width
    0.9 mm (Even) * Off-Bezel
    5.3 mm (T/L/R),11.0 mm (B) * On-Bezel
    Dimension (W x H x D)
    (Head) 1220.3 x 696.8 x 4.9 mm
    (Signage Box) 782.8 x 238.4 x 34.7 mm
  • Weight
    10 kg (Set)
    Carton Dimensions (W x H x D)
    1,350 x 837 x 250 mm
  • Packed Weight
    22.9 kg
Environment Conditions
  • Operation Temperature Range
    0°C ~ 40°C
    Operation Humidity Range
    10% ~ 80%
Power
  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power
  • Power Consumption (Typ. / Max.)
    309 W / 318 W * 8 Color Bar Based
Standard(Certification)
  • Safety
    IEC 60950-1 / EN 60950-1 / UL 60950-1
    EMC
    FCC Class "A" / CE / KC
  • ErP / Energy Star
    Yes (EU Only) / No
Media Player Compatibility
  • OPS type compatible
    No
    External Media Player Attachable
    Yes
Software Compatibility
  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control+ / Control
Accessory
  • Basic
    Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p), FFC Cables (for Connection Between Panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable), Wall Fixers, Wall Fixer Install Guide, Install Guide Sheets, Tapes (for Cabling and Dust Proof), Screws
  • Dimension
    • [Dimension]55EJ5E.dwg
    • [Dimension]55EJ5E.pdf
  • Datasheet
    • EJ5E leaflet_web_11810.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
