55EJ5G component-copyModelName

Flat OLED Signage

LG Flat OLED Signage, Front view with infill image, 55EJ5G, thumbnail 1

LG Flat OLED Signage, Front view, 55EJ5G, thumbnail 2

LG Flat OLED Signage, -45 degree side view, 55EJ5G, thumbnail 3

LG Flat OLED Signage, -90 degree side view, 55EJ5G, thumbnail 4

LG Flat OLED Signage, +45 degree side view, 55EJ5G, thumbnail 5

LG Flat OLED Signage, +90 degree side view, 55EJ5G, thumbnail 6

LG Flat OLED Signage, Rear view, 55EJ5G, thumbnail 7

LG Flat OLED Signage, Top view, 55EJ5G, thumbnail 8

Discontinued

55EJ5G component-copyModelName

Flat OLED Signage

Key Features

Brightness(Typ.): 400 cd/m² (APL 25%)
Bezel: 0.9 mm (Even, Off bezel)
Depth: 4.9mm (Head)
Interface: HDMI/ USB 2.0(2)/ DP/ Audio Out/ RS232C/ RJ45/ IR

Inquiry to Buy

Add to Compare

component-OBScountrySelectDesc

Key Features

Brightness(Typ.): 400 cd/m² (APL 25%)
Bezel: 0.9 mm (Even, Off bezel)
Depth: 4.9mm (Head)
Interface: HDMI/ USB 2.0(2)/ DP/ Audio Out/ RS232C/ RJ45/ IR

Add to Compare

component-OBScountrySelectDesc

component-copyModel-toastMsg

Flat OLED Signage

Artistic Space beyond Display, LG Wallpaper OLED Signage

This sophisticated wallpaper OLED signage achieves the best possible picture quality, concealing its presence by blending in with the wall. Minimal space is required for installation, which simplifies the construction process. The luxurious atmosphere generated with this signage will provide customers with an extraordinary experience, making them feel like VIPs.

A display promoting a new product is installed in the store's window.

* All images are for illustrative purposes only.

LG OLED Signage shows better contrast between black and white than ordinary LCD.

Absolute Black

Equipped with over 8 million self-lighting pixels operating individually, LG OLED Signage reproduces absolute blacks with no light bleed and offers infinite contrast.

LG OLED Signage has a variety of colors rather than LCD to express the object more vividly.

Rich Color

LG OLED Signage provides richness in all colors, bringing colors to life with great accuracy and vividness.

LG's OLED display is very slim and light with a depth of 4.9mm and a weight of 6.6kg.

Splendid Design

LG’s OLED technology unlocks the new worlds of design flexibility with unbelievably lightweight and slim display. The advantages the OLED display brings are countless from the easier installation to a sleek look.

The edge of the display on the wall is so thin that it looks as if content is playing directly from the wall.

Hide in Plain Sight

The subtle edge of the wallpaper OLED totally blends in with the wall, giving audiences the sensation that content is being played directly within the wall itself. Integrating with and adding to a luxurious interior design, the wallpaper OLED is an effective method for delivering advertisements and information.

A large screen was made by tiling several screens.

N×N Expandable Screen Size

By tiling up displays horizontally and vertically, the screen size can be as large as users want. Expansive, large screens are more effective at moving viewers by providing an incredibly immersive viewing experience.

Multiple displays are managed and monitored through LAN daisy chain.

LAN Daisy Chain Management

A LAN daisy chain is supported, allowing you to execute commands to control and monitor the displays and even update their firmware.

EJ5G series has a front installation feature, making it easier to tile displays.

Wall Fixers Optimized for Simple Tiling

The overall installation process of the wallpaper OLED has gotten much easier. Once the dedicated wall fixers are driven into a wall, a display can be easily hung on them. Video wall tiling has become more convenient, thanks to its front installation feature, which departs from the conventional side-sliding method.

Cables are so flexible that it is easily embedded in a wall or other structures.

Enhanced Flexibility of Cables

As a result of in-depth consideration of usage scenarios, improvements have been made to the flexibility of common cables connecting the display to the signage box. These new cables are pliable enough to be easily embedded in a wall or other structures.

Panel

Screen Size

55"

Panel Technology

OLED
Back Light Type

OLED

Aspect Ratio

16:9
Native Resolution

1920x1080 (FHD)

Refresh Rate

120Hz
Brightness

150/400nit (APL 100%/25%)

Contrast Ratio

150,000 : 1
Dynamic CR

No

Color gamut

BT709 120%
Viewing Angle(H x V)

178x178

Color Depth

10bit(R), 1.07Bilion colors
Response Time

1ms (G to G), 8ms (MPRT)

Surface Treatment(Haze)

Hard coating (2H)
Reflectance Typ. 1.2%
Life time

30,000 Hrs (Typ.)

Operation Hours (Hours/Day)

18/7 (Moving Content Only)
Portrait / Landscape

Yes

Connectivity
(Jack Interface)

Input - Digital - HDMI

Yes (1), HDCP1.4

Input - Digital - DP

Yes (1), HDCP1.3
Input - Digital - DVI-D

No

Input - Analog - RGB

No
Input - Audio In

No

Input - RS232C IN

Yes (1)
Input - RJ45(LAN)

Yes (1)

Input - IR IN

Yes (1), External IR Receiver
Input - USB

USB2.0 Type A(2)

Output - DP Out

Yes (1)
Output - Audio Out

Yes (1)

Output - Externel Speaker Out

No
Output - RS232C OUT

Yes (1) (w/ IR out)

Output - RJ45(LAN)

Yes (1)

Mechanical Specification

Bezel Color

Black

Bezel Width

TBD
Even Bezel : 0.9mm (Off Bezel)
T/R/L/B : 5.3/11.0/5.3/5.3mm (On Bezel)
Weight(Head)

TBD
6.6Kg (Head)
3.4Kg (Signage Box)

Weight(Head+Stand)

No
Packed Weight

TBD
22.9Kg

Monitor Dimension(W x H x D)

TBD
1220.3 x 696.8 x 4.9mm (Head)
782.8x 238.4 x 34.7mm (Signage Box)
Monitor Dimensions with Stand(W x H x D)

No

Carton Dimensions(W x H x D) (Box outer size)

TBD 1329 x 782 x 191mm
Handle

No

VESA^TM Standard Mount Interface

No

Key Feature

HW - Internal Memory

16GB

HW - Wi-Fi - Built-in

No
HW - Sensor - Temperature Sensor

Yes

HW - Sensor - Auto Brightness sensor

No
HW - Sensor - Pixel sensor

No

HW - Sensor - Proximity Sensor

No
HW - Sensor - Current Sensor

No

HW - Power Indicator

No
HW - Local Key Operation

No

HW - FAN

No
SW - webOS ver.

webOS4.0

SW - Embedded CMS - Local Contents Scheduling

Yes
SW - Embedded CMS - Group Manager

Yes

SW - USB Plug & Play

Yes
SW - Fail over

Yes

SW - Background Image - Booting Logo Image

No
SW - Background Image - No Signal Image

No

SW - Sync Mode - RS-232C Sync

Yes
SW - Sync Mode - Local Network Sync

Yes

SW - Multi-screen - PIP

No
SW - Multi-screen - PBP

No

SW - Screen Share

No
SW - Video Tag

Yes (4)

SW - Play via URL

No
SW - Rotation - Screen Rotation

Yes

SW - Rotation - External Input Rotation

Yes
SW - Gapless Playback

Yes

SW - Tile Mode Setting

Yes
SW - Setting Data Cloning

Yes

SW - SNMP

Yes
SW - ISM Method

Yes

SW - Auto Set ID

Yes
SW - Status Mailing

Yes

SW - Control Manager

Yes
SW - 3rd Party Compatibility - Crestron Inside

Yes

SW - Power - Smart Energy Saving

No
SW - Power - PM mode

Yes

SW - Power - Wake on LAN

Yes
SW - Power - Network Ready

No

SW - Beacon

No
SW - HDMI-CEC

Yes

SW - SI Server Setting

Yes
SW - webRTC

No

SW - Pro:Idiom

Yes

Environment Conditions

Operation Temperature

0 °C to 40 °C

Operation Humidity

10 % to 80 %

Power

Power Supply

AC 100-240V~, 50/60Hz

Power Type

Built-In Power

Power Consumption

Typ.

309W

Max.

318W
BTU (British Thermal Unit)

1054 BTU/Hr(Typ.), 1085 BTU/Hr(Max)

Smart Enegy Saving

No
DPM

3W

Power off

0.5W

Sound

Speaker

No

Certification

Safety

IEC 60950-1 / EN 60950-1 / UL 60950-1

EMC

FCC Class "A" / CE / KC
ErP / Energy Star

Yes / No

ePEAT(US only)

No

OPS Compatibility

OPS Type Compatible

No

OPS Power Built In

No

Software Compatibility

SuperSign CMS

Yes (v3.0)

SuperSign Control / Control+

Yes (v1.7 / v1.9)
SuperSign WB

Yes (v3.7.15)

SuperSign Media Editor

Yes (v3.7)
Signage 365 Care

Yes (v2.9)

Language

OSD

English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic

Accessory

Basic

Remote Controller(include battery 2ea), Power Cord, QSG, IR receiver, Regulation Book, Phone to RS232C Gender,RS232 cable(4p-4p), FFC Cables(1600mmx4ea for connection between panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable), Wall Fixer(4EA), Wall Fixer Install Guide, Install Guide Sheet(2EA), Tape(10EA for Cabling/2EA for Dust proof), Screw(M4xL25,10EA / M3xL5.5,8EA)

Optional

No

Special Feature

Overlay Touch Compatibility

No

Dimension
- 55EJ5G-B_2D.dwg
- 55EJ5G-B_2D.pdf
Software

To download Software, Please visit the Software Download Page (Click).
Manual

To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
