All Spec
PHYSICAL PARAMETERS
-
Pixel Configuration
-
3 in 1
-
Pixel Pitch (mm)
-
2.500
-
Module Resolution (W x H)
-
120 × 135
-
Module Dimensions (W x H, mm)
-
300 × 337.5
-
Weight per Module (kg)
-
0.64 (-RK,-CK)/ 1.40 (-CKF)
-
No. of Modules per Cabinet (W × H)
-
2x2 (-RK)/ 1x2 (-CK,-CKF)
-
Cabinet Resolution (W × H)
-
240x135 (-RK)/ 120x135 (-CK, -CKF)
-
Cabinet Dimensions (W × H × D)
-
600x337.5x34 (-RK)/
300x337.5x29.7 (-CK)/
300x337.5x35.6 (-CKF, Cabinet Mounting Depth)
-
Cabinet Surface Area (m²)
-
0.203 (-RK)/ 0.101 (-CK, -CKF)
-
Weight per Cabinet (kg/unit)
-
5.3 (-RK)/ 4.0 (-CK)/
3.1 (-CKF, Weight Changes for Different Curves)
-
Weight per Square Meter (kg/m²)
-
26.2 (-RK)/ 39.0 (-CK)/ 30.6 (-CKF)
-
Physical Pixel Density (pixels/m²)
-
160,000
-
Flatness of Cabinet
-
± 0.1 mm
-
Cabinet Material
-
Die-casting Aluminum (-RK)/
Aluminum Machine (-CK, CKF)
-
Service Access
-
Front
OPTICAL PARAMETER
-
Max Brightness (After Calibration)
-
800
-
Color Temperature
-
3,200-9,300 (K)
-
Visual Viewing Angle (H×V)
-
160 × 160
-
Brightness Uniformity
-
97%
-
Color Uniformity
-
± 0.003 Cx,Cy
-
Contrast Ratio
-
5,000 : 1
-
Processing Depth (bit)
-
14 (HDR10, HDR10 Pro)
ELECTRICAL PARAMETER
-
Power Consumption (W/cabinet, Max.)
-
100 (-RK)/ 55 (-CK, -CKF)
-
Power Consumption (W/cabinet, Avg.)
-
34 (-RK)/ 18 (-CK, CKF)
-
Power Consumption (W/m², Max.)
-
494 (-RK)/ 543 (-CK, -CKF)
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50 / 60
-
Refresh Rate (Hz)
-
3,840
OPERATION CONDITIONS
-
Lifetime (Hours to Half Brightness)
-
100,000
-
Operating Temperature (°C)
-
-10° to +45°
-
Operating Humidity
-
0 - 80 % RH
-
IP rating Front / Rear
-
IP30 / IP30
CONTROLLER
-
Controller
-
CVCA, LCIN006, LCIN008 (4K)
90 DEGREE CORNER CUT
-
90 Degree Corner Cut
-
Yes
