Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
1.56
Screen Resolution (WxH)
1,920x1,080
Module Dimensions (WxH, mm)
250 x 281.25
No. of Modules per Screen (WxH)
12x6 (Total 72)
Screen Dimensions (W x H x D, mm, including bezel)
3,004.6 x 1,692.1 x 36.5 (Thickest 70)
Screen Surface Area (㎡)
5.06
Screen Weight (kg)
129
Physical Pixel Density (pixels/m²)
409,600
Flatness of Unit Case (mm)
±0.2
Unit Case material
Aluminum
Service access
Front
Min. Brightness (After Calibration)
500 nit
Color Temperature
3,200 ~ 9,300
Visual Viewing Angle (H × V)
160° x 160°
Brightness Uniformity
98%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3,000:1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Power Consumption (W/screen, Max.)
2,000
Power Consumption (W/screen, Avg.)
800
Power Consumption (W/m², Max.)
395
Power Consumption (BTU/h/Screen, Max.)
6,824
Power Consumption (BTU/h/Screen, Avg.)
2,730
Power Consumption (BTU/h/m², Max.)
1,348
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
≥2880
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0℃ to +40℃
Operating Humidity
<90%RH(without condensation)
IP rating Front
IP30
IP rating Rear
IP20
Speaker
Built-in(9W+9W)
Certification
CE,FCC,ETL,CB
Environment
RoHS, REACH
Controller
Embedded
