Semua Spesifikasi
PHYSICAL PARAMETERS
-
Pixel Configuration
-
3 in 1 SMD
-
Pixel Pitch(mm)
-
2.00
-
Module Resolution (WxH)
-
120x90
-
Module Dimensions(WxH,mm)
-
240x180
-
Weight per Module (kg)
-
0.36
-
No. of Modules per Unit Case (WxH)
-
2x3
-
Unit Case Resolution (WxH)
-
240x270
-
Unit Case Dimensions (W x H x D, mm)
-
480x540x40
-
Unit Case Surface Area (㎡)
-
0.260
-
Weight per Unit Case (kg/unit)
-
5.0
-
Weight per Square Meter (kg/㎡)
-
19.8
-
Physical Pixel Density (pixels/㎡)
-
250,000
-
Flatness of Unit Case (mm)
-
±0.2
-
Unit Case material
-
Die casting alluminum
-
Service access
-
Front or Rear
OPTICAL SPECIFICATIONS
-
Min. Brightness (After Calibration)
-
300 ~ 1,000
-
Color Temperature
-
3,200 ~ 9,300
-
Visual Viewing Angle (Horizontal)
-
160
-
Visual Viewing Angle (Vertical)
-
140
-
Brightness Uniformity
-
≥97%
-
Color Uniformity
-
±0.015Cx,Cy
-
Contrast Ratio
-
6,000
-
Processing Depth (bit)
-
16
ELECTRICAL SPECIFICATIONS
-
Power Consumption (W/Unit, Avg.)
-
170
-
Power Consumption (W/Unit, Max.)
-
330
-
Power Consumption (W/㎡, Max.)
-
1270(@1,000nit)
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50 / 60
-
Refresh Rate (Hz)
-
3,840
OPERATION SPECIFICATIONS
-
Lifetime (Half brightness)* * The Lifetime(Half brightness) spec is subject to LED package spec.
-
100,000
-
Operating Temperature(℃)
-
0∘to +40∘
-
Operating Humidity
-
10-80%RH(TBD)
CONTROLLER
-
Controller
-
LCLG003
