Cooling(Nom) - kW
3.6
Cooling(Nom) - kcal/h
3,100
Cooling(Nom) - Btu/h
12,300
Heating(Nom) - kW
4.0
Heating(Nom) - kcal/h
3,400
Heating(Nom) - Btu/h
13,600
Power Input(H / M / L) - W
41 / 34 / 29
Casing
Galvanized Steel Plate
Body - ㎜
900 x 190 x 700
Body - inch
35-7/16 × 7-15/32 × 27-9/16
Rows x Columns x FPI
2 x 11 x 18
Face Area - ㎡
0.17
Type
Sirocco Fan
Motor Output × Number - W × No.
19 x 1, 5 x 1
Running Current - A
0.76
Air Flow Rate(H / M / L) (High Mode-Factory Set) - m³/min
10.0 / 8.5 / 7.0
Air Flow Rate(H / M / L) (High Mode-Factory Set) - ft³/min
360 / 310 / 250
External Static Pressure (High Mode) - ㎜Aq(Pa)
2.54 (25)
Air Flow Rate (H / M / L) (Standard Mode) - m³/min
10.0 / 8.5 / 7.0
Air Flow Rate (H / M / L) (Standard Mode) - ft³/min
360 / 310 / 250
External Static Pressure (Standard Mode) - ㎜Aq(Pa)
0 (0)
Drive
Direct
Motor type
BLDC
Temperature Control
Microprocessor, Thermostat for cooling and heating
Sound Absorbing Thermal Insulation Material
Foamed polystyrene
Safety Device
Fuse
Liquid Side - ㎜(inch)
Ø 6.35 (1/4)
Gas Side - ㎜(inch)
Ø 12.7 (1/2)
Drain Pipe(Internal Dia.) - ㎜(inch)
Ø 25.4 (1)
Body - kg(lbs)
23 (50.7)
H / M / L - dB(A)
30 / 27 / 25
H / M / L - dB(A)
50 / 47 / 46
Power Supply - Ø, V, Hz
1, 220-240, 50
1, 220, 60
Refrigerant Control
EEV
Transmission Cable - mm² × Cores
1.0 ~ 1.5 × 2C
