Cooling(Nom) - kW
7.1
Cooling(Nom) - kcal/h
6,100
Cooling(Nom) - Btu/h
24,200
Heating(Nom) - kW
8.0
Heating(Nom) - kcal/h
6,900
Heating(Nom) - Btu/h
27,300
Power Input(H / M / L) - W
103 / 63 / 48
Casing
Galvanized Steel Plate
Body - ㎜
1,100 × 190 × 700
Body - inch
43-5/16 × 7-15/32 × 27-9/16
Rows x Columns x FPI
2 x 11 x 18
Face Area - ㎡
0.21
Type
Sirocco Fan
Motor Output × Number - W × No.
19 x 2
Running Current - A
0.97
Air Flow Rate(H / M / L) (High Mode-Factory Set) - m³/min
20.0 / 16.0 / 12.0
Air Flow Rate(H / M / L) (High Mode-Factory Set) - ft³/min
710 / 570 / 430
External Static Pressure (High Mode) - ㎜Aq(Pa)
2.54 (25)
Air Flow Rate (H / M / L) (Standard Mode) - m³/min
20.0 / 16.0 / 12.0
Air Flow Rate (H / M / L) (Standard Mode) - ft³/min
710 / 570 / 430
External Static Pressure (Standard Mode) - ㎜Aq(Pa)
0 (0)
Drive
Direct
Motor type
BLDC
Temperature Control
Microprocessor, Thermostat for cooling and heating
Sound Absorbing Thermal Insulation Material
Foamed polystyrene
Safety Device
Fuse
Liquid Side - ㎜(inch)
Ø 9.52 (3/8)
Gas Side - ㎜(inch)
Ø 15.88 (5/8)
Drain Pipe(Internal Dia.) - ㎜(inch)
Ø 25.4 (1)
Body - kg(lbs)
27 (59.5)
H / M / L - dB(A)
36 / 33 / 28
H / M / L - dB(A)
63 / 59 / 55
Power Supply - Ø, V, Hz
1, 220-240, 50
1, 220, 60
Refrigerant Control
EEV
Transmission Cable - mm² × Cores
1.0 ~ 1.5 × 2C
