Semua Spesifikasi
CAPACITY
-
Cooling(Rated) - kW
-
33.6
-
Cooling(Rated) - kcal/h
-
28,900
-
Cooling(Rated) - Btu/h
-
114,600
-
Heating(Rated) - kW
-
33.6
-
Heating(Rated) - kcal/h
-
28,900
-
Heating(Rated) - Btu/h
-
114,600
HORSE POWER
-
Horse Power - HP
-
12
INPUT
-
Cooling(Rated) - kW
-
8.90
-
Heating(Rated) - kW
-
9.10
EER
-
EER(Rated)
-
3.78
COP
-
COP(Rated)
-
3.69
POWER FACTOR
-
Rated
-
0.93
EXTERIOR
-
Color
-
Warm Gray / Dawn Gray
-
RAL code
-
NL503K / NA507K
HEAT EXCHANGER
-
Type
-
Wide Louver Plus
COMPRESSOR
-
Type
-
Hermetically Sealed Scroll
-
Piston Displacement - ㎤/rev
-
62.1
-
Number of Revolution - rev/min
-
3,600
-
Motor Output × Number - W
-
5,300
-
Starting Method
-
Direct On Line
-
Oil Type
-
FVC68D(PVE)
FAN
-
Type
-
Propeller fan
-
Motor Output × Number - W
-
1,200
-
Air Flow Rate(High) - ㎥/min
-
240
-
Air Flow Rate(High) - ft³/min
-
8,476
-
Drive
-
DC INVERTER
-
Discharge - Side / Top
-
TOP
PIPE CONNECTIONS
-
Liquid Pipe - ㎜(inch)
-
Ø 12.7 (1/2)
-
Gas Pipe - ㎜(inch)
-
Ø 28.58 (1-1/8)
DIMENSIONS (W × H × D)
-
Dimensions(W x H x D) - ㎜
-
(930 × 1,690 × 760)
-
Dimensions(W x H x D) - inch
-
(36-5/8 × 66-17/32 × 29-29/32)
NET WEIGHT
-
Net Weight - kg
-
175
-
Net Weight - lbs
-
386
GROSS WEIGHT
-
Gross Weight - kg
-
185
-
Gross Weight - lbs
-
408
SOUND PRESSURE LEVEL
-
Cooling - dB(A)
-
59.0
-
Heating - dB(A)
-
60.0
SOUND POWER LEVEL
-
Cooling - dB(A)
-
79.0
-
Heating - dB(A)
-
80.0
PROTECTION DEVICES
-
High pressure protection
-
High pressure sensor / High pressure switch
-
Compressor/Fan
-
Over-heat protection / Fan driver overload protector
-
Inverter
-
Over-heat protection / Over-current protection
COMMUNICATION CABLE
-
Communication Cable - No.×㎟(VCTF-SB)
-
2C × 1.0 ~ 1.5
REFRIGERANT
-
Refrigerant name
-
R410A
-
Precharged Amount in factory - kg
-
4.7
-
Precharged Amount in factory - lbs
-
10.4
-
GWP
-
2087.5
-
tCO2-eq
-
9.8
-
Control
-
Electronic Expansion Valve
POWER SUPPLY
-
Power Supply - Ø, V, Hz
-
3, 380-415, 50
3, 380, 60
NUMBER OF MAXIMUM CONNECTABLE INDOOR UNITS
-
Number of Maximum Connectable Indoor Units - m(ft)
-
20 (30)
