Cooling(Rated) - kW
33.6
Cooling(Rated) - Btu/h
114,600
Heating(Rated) - kW
37.8
Heating(Rated) - Btu/h
129,000
Horse Power - HP
12
Cooling(Rated) - kW
7.91
Heating(Rated) - kW
8.06
EER(Rated)
4.25
COP(Rated)
4.69
Rated
0.93
Color
Warm Gray / Dawn Gray
RAL code
NL503K / NA507K
Type
Wide Louver Plus
Type
Hermetically Sealed Scroll
Piston Displacement - ㎤/rev
62.1
Number of Revolution - rev/min
3,600
Motor Output × Number - W × No.
5,300 × 1
Starting Method
Direct On Line
Oil Type
FVC68D(PVE)
Type
Propeller fan
Motor Output × Number - W × No.
1,200 × 1
Air Flow Rate(High) - ㎥/min × No.
240 × 1
Air Flow Rate(High) - ft³/min × No.
8,476 × 1
External Static Pressure (Max, Pa)
80
Drive
DC INVERTER
Discharge - Side / Top
TOP
Liquid Pipe - ㎜(inch)
Ø 12.7 (1/2)
Gas Pipe - ㎜(inch)
Ø 28.58 (1-1/8)
Dimensions(W x H x D) - ㎜ × No.
(930 × 1,690 × 760) × 1
Dimensions(W x H x D) - inch × No.
(36-5/8 × 66-17/32 × 29-29/32) × 1
Net Weight - kg × No.
199 × 1
Net Weight - lbs × No.
439 × 1
Cooling - dB(A)
59.0
Heating - dB(A)
60.0
Cooling - dB(A)
79.0
Heating - dB(A)
80.0
High pressure protection
High pressure sensor / High pressure switch
Inverter
Over-heat protection / Over-current protection
Compressor/Fan
Over-heat protection / Fan driver overload protector
Communication Cable - No.×㎟(VCTF-SB)
2C × 1.0 ~ 1.5
Refrigerant name
R410A
Precharged Amount in factory - kg
10.0
Precharged Amount in factory - lbs
22.0
tCO2-eq
20.9
Control
Electronic Expansion Valve
Power Supply - Ø, V, Hz
3, 380-415, 50
3, 380, 60
Number of Maximum Connectable Indoor Units - m(ft)
20 (30)
