Cooling(Rated) - kW
50.4
Cooling(Rated) - Btu/h
172,000
Heating(Rated) - kW
56.7
Heating(Rated) - Btu/h
193,500
Horse Power - HP
18
Cooling(Rated) - kW
10.96
Heating(Rated) - kW
12.06
EER(Rated)
4.60
COP(Rated)
4.70
Rated
0.93
Color
Warm Gray / Dawn Gray
RAL code
NL503K / NA507K
Type
Wide Louver Plus
Type
Hermetically Sealed Scroll
Piston Displacement - ㎤/rev × No.
62.1 × 1 + 43.8 × 1
Number of Revolution - rev/min × No.
3,600 × 2
Motor Output × Number - W × No.
5,300 × 1 + 4,200 × 1
Starting Method
Direct On Line
Oil Type
FVC68D(PVE)
Type
Propeller fan
Motor Output × Number - W × No.
900 × 2
Air Flow Rate(High) - ㎥/min × No.
320 × 1
Air Flow Rate(High) - ft³/min × No.
11,301 × 1
External Static Pressure (Max, Pa)
80
Drive
DC INVERTER
Discharge - Side / Top
TOP
Liquid Pipe - ㎜(inch)
Ø 15.88 (5/8)
Gas Pipe - ㎜(inch)
Ø 28.58 (1-1/8)
Dimensions(W x H x D) - ㎜ × No.
(1,240 × 1,690 × 760) × 1
Dimensions(W x H x D) - inch × No.
(48-13/16 × 66-17/32 × 29-29/32) × 1
Net Weight - kg × No.
261 × 1
Net Weight - lbs × No.
575 × 1
Cooling - dB(A)
61.0
Heating - dB(A)
62.0
Cooling - dB(A)
85.0
Heating - dB(A)
86.0
High pressure protection
High pressure sensor / High pressure switch
Compressor/Fan
Over-heat protection / Fan driver overload protector
Inverter
Over-heat protection / Over-current protection
Communication Cable - No.×㎟(VCTF-SB)
2C × 1.0 ~ 1.5
Refrigerant name
R410A
Precharged Amount in factory - kg
13.0
Precharged Amount in factory - lbs
28.7
tCO2-eq
27.1
Control
Electronic Expansion Valve
Power Supply - Ø, V, Hz
3, 380-415, 50
3, 380, 60
Number of Maximum Connectable Indoor Units - m(ft)
29 (45)
