Cooling(Rated) - kW
72.8
Cooling(Rated) - kcal/h
62,600
Cooling(Rated) - Btu/h
248,400
Heating(Rated) - kW
72.8
Heating(Rated) - kcal/h
62,600
Heating(Rated) - Btu/h
248,400
Horse Power - HP
26
Cooling(Rated) - kW
20.80
Heating(Rated) - kW
20.50
EER(Rated)
3.50
COP(Rated)
3.55
Rated
0.93
Color
Warm Gray / Dawn Gray
RAL code
NL503K / NA507K
Type
Wide Louver Plus
Type
Hermetically Sealed Scroll
Piston Displacement - ㎤/rev × No.
62.1 × 2
Number of Revolution - rev/min × No.
3,600 × 2
Motor Output × Number - W × No.
5,300 × 2
Starting Method
Direct On Line
Oil Type
FVC68D(PVE)
Type
Propeller fan
Motor Output × Number - W × No.
900 × 2
Air Flow Rate(High) - ㎥/min
320
Air Flow Rate(High) - ft³/min
11,301
Drive
DC INVERTER
Discharge - Side / Top
TOP
Liquid Pipe - ㎜(inch)
Ø 19.05 (3/4)
Gas Pipe - ㎜(inch)
Ø 34.9 (1-3/8)
Dimensions(W x H x D) - ㎜
(1,240 × 1,690 × 760)
Dimensions(W x H x D) - inch
(48-13/16 × 66-17/32 × 29-29/32)
Net Weight - kg
250
Net Weight - lbs
551
Gross Weight - kg
264
Gross Weight - lbs
582
Cooling - dB(A)
65.0
Heating - dB(A)
67.0
Cooling - dB(A)
88.0
Heating - dB(A)
90.0
High pressure protection
High pressure sensor / High pressure switch
Compressor/Fan
Over-heat protection / Fan driver overload protector
Inverter
Over-heat protection / Over-current protection
Communication Cable - No.×㎟(VCTF-SB)
2C × 1.0 ~ 1.5
Refrigerant name
R410A
Precharged Amount in factory - kg
11
Precharged Amount in factory - lbs
24.3
GWP
2087.5
tCO2-eq
23.0
Control
Electronic Expansion Valve
Power Supply - Ø, V, Hz
3, 380-415, 50
3, 380, 60
Number of Maximum Connectable Indoor Units - m(ft)
42 (64)
