Semua Spesifikasi
CAPACITY
-
Cooling(Rated) - kW
-
9.0
-
Cooling(Rated) - kcal/h
-
7,740
-
Cooling(Rated) - Btu/h
-
30,700
-
Heating(Rated) - kW
-
10.0
-
Heating(Rated) - kcal/h
-
8,600
-
Heating(Rated) - Btu/h
-
34,100
INPUT
-
Cooling(Rated) - kW
-
2.25
-
Heating(Rated) - kW
-
2.25
POWER FACTOR
-
Rated
-
0.93
CASING COLOR
-
Casing Color
-
Warm Gray
HEAT EXCHANGER
-
Type
-
Wide Louver Plus
COMPRESSOR
-
Type
-
BLDC Inverter Twin Rotary
-
Piston Displacement - ㎤/rev
-
44.2
-
Number of Revolution - rev/min
-
3,600
-
Motor Output × Number - W × No.
-
4,000 x 1
-
Starting Method
-
DC Inverter Starting
-
Oil Type
-
FVC68D(PVE)
-
Oil Charge - cc
-
1,300
FAN
-
Type
-
Axial Flow Fan
-
Motor Output × Number - W × No.
-
124 x 1
-
Air Flow Rate(High) - ㎥/min
-
60
-
Air Flow Rate(High) - ft³/min
-
2,119
-
Drive
-
DC INVERTER
-
Discharge - Side / Top
-
Side
PIPE CONNECTIONS
-
Liquid Pipe - ㎜(inch)
-
Ø 9.52 (3/8)
-
Gas Pipe - ㎜(inch)
-
Ø 15.88 (5/8)
DIMENSIONS (W × H × D)
-
Dimensions(W x H x D) - ㎜
-
950 x 834 x 330
-
Dimensions(W x H x D) - inch
-
37-13/32 × 32-27/32 × 13
NET WEIGHT
-
Net Weight - kg
-
70
-
Net Weight - lbs
-
154
SOUND PRESSURE LEVEL
-
Cooling - dB(A)
-
49
-
Heating - dB(A)
-
51
SOUND POWER LEVEL
-
Sound power Level - dB(A)
-
65
PROTECTION DEVICES
-
High pressure protection
-
High pressure sensor / High pressure switch
-
Compressor/Fan
-
Over-heat protection / Fan driver overload protector
-
Inverter
-
Over-heat protection / Over-current protection
COMMUNICATION CABLE
-
Communication Cable - No.×㎟(VCTF-SB)
-
2C × 1.0 ~ 1.5
REFRIGERANT
-
Refrigerant name
-
R410A
-
Precharged Amount in factory - kg
-
1.8
-
Precharged Amount in factory - lbs
-
4.0
-
Control
-
Electronic Expansion Valve
POWER SUPPLY
-
Power Supply - Ø, V, Hz
-
1, 220-240, 50
1, 220, 60
NUMBER OF MAXIMUM CONNECTABLE INDOOR UNITS
-
Number of Maximum Connectable Indoor Units
-
6
