Cooling(Rated) - kW
15.5
Cooling(Rated) - kcal/h
13,300
Cooling(Rated) - Btu/h
52,900
Heating(Rated) - kW
18.0
Heating(Rated) - kcal/h
15,500
Heating(Rated) - Btu/h
61,400
Cooling(Rated) - kW
3.96
Heating(Rated) - kW
4.09
Rated
0.93
Casing Color
Warm Gray
Type
Wide Louver Plus
Type
Hermetic Motor Compressor
Piston Displacement - ㎤/rev
44.2
Number of Revolution - rev/min
3,600
Motor Output × Number - W × No.
4,000 x 1
Starting Method
DC Inverter Starting
Oil Type
FVC68D(PVE)
Oil Charge - cc
1,300
Type
Axial Flow Fan
Motor Output × Number - W × No.
124 x 2
Air Flow Rate(High) - ㎥/min
110
Air Flow Rate(High) - ft³/min
3,885
Drive
DC INVERTER
Discharge - Side / Top
Side
Liquid Pipe - ㎜(inch)
Ø 9.52 (3/8)
Gas Pipe - ㎜(inch)
Ø 19.05 (3/4)
Dimensions(W x H x D) - ㎜ × No.
(950 ×1,380 ×330) x 1
Dimensions(W x H x D) - inch × No.
(37-13/32 × 54-11/32 × 13) x 1
Net Weight - kg
94
Net Weight - lbs
207
Cooling - dB(A)
52
Heating - dB(A)
54
Sound power Level - dB(A)
69
High pressure protection
High pressure sensor / High pressure switch
Compressor/Fan
Over-heat protection / Fan driver overload protector
Inverter
Over-heat protection / Over-current protection
Communication Cable - No.×㎟(VCTF-SB)
2C × 1.0 ~ 1.5
Refrigerant name
R410A
Precharged Amount in factory - kg
3.0
Precharged Amount in factory - lbs
6.6
Control
Electronic Expansion Valve
Power Supply - Ø, V, Hz
1, 220-240, 50
1, 220, 60
Number of Maximum Connectable Indoor Units
13
