Cooling(Rated) - kW
7.2
Cooling(Rated) - kcal/h
6,191
Cooling(Rated) - kW
1.80
Rated
1
Casing Color
Warm Gray
Type
Wide Louver Plus
Type
Hermetic Motor Compressor
Piston Displacement - ㎤/rev
18
Number of Revolution - rev/min
6,000
Motor Output × Number - W × No.
1,500 x 1
Starting Method
DC Inverter Starting
Oil Type
FVC68D(PVE)
Oil Charge - cc
670
Type
Axial Flow Fan
Motor Output × Number - W × No.
85.4 x 1
Air Flow Rate(High) - ㎥/min
44
Air Flow Rate(High) - ft³/min
1,553
Drive
DC INVERTER
Discharge - Side / Top
Side
Liquid Pipe - ㎜(inch)
Ø 9.52 (3/8)
Gas Pipe - ㎜(inch)
Ø 15.88 (5/8)
Dimensions(W x H x D) - ㎜
870 x 655 x 320
Dimensions(W x H x D) - inch
34-1/4 × 25-25/32 × 12-19/32
Net Weight - kg
45
Net Weight - lbs
99.2
Cooling - dB(A)
50
High pressure protection
High pressure sensor / High pressure switch
Compressor/Fan
Over-heat protection / Fan driver overload protector
Inverter
Over-heat protection / Over-current protection
Communication Cable - No.×㎟(VCTF-SB)
2C × 1.0 ~ 1.5
Refrigerant name
R410A
Precharged Amount in factory - kg
1.0
Precharged Amount in factory - lbs
2.2
Control
Electronic Expansion Valve
Power Supply - Ø, V, Hz
1, 220-240, 50
Number of Maximum Connectable Indoor Units
3
