Semua Spesifikasi
CAPACITY
-
Nominal Capacity - CMH(CFM)
-
800 (471)
ERV MODE
-
Operating Step
-
Super-high / High / Low
-
Running Current(SH / H / L) - A
-
2.13 / 1.75 / 1.00
-
Power Input(SH / H / L) - W
-
328 / 266 / 144
-
Air Flow(SH / H / L) - CMH(CFM)
-
800 / 800/ 660
(471 / 471 / 388)
-
External Static Pressure(SH / H / L) - Pa(inWTR)
-
160 / 100 / 50
(0.64 / 0.40 / 0.20)
-
Temperature Exchange Efficiency(SH / H / L) - %
-
82 / 82 / 83
-
Enthalpy Exchange Efficiency Heating(SH / H / L) - %
-
73 / 73 / 76
-
Enthalpy Exchange Efficiency Cooling(SH / H / L) - %
-
66 / 66 / 70
-
Sound pressure level(SH / H / L) - ㏈(A)
-
40 / 36 / 32
-
Sound power level(SH / H / L) - ㏈(A)
-
56 / 53 / 47
BYPASS MODE
-
Operating Step
-
Super-high / High / Low
-
Running Current(SH / H / L) - A
-
2.13 / 1.75 / 1.00
-
Power Input(SH / H / L) - W
-
328 / 266 / 144
-
Air Flow(SH / H / L) - CMH(CFM)
-
800 / 800/ 660
(471 / 471 / 388)
-
External Static Pressure(SH / H / L) - Pa(inWTR)
-
160 / 100 / 50
(0.64 / 0.40 / 0.20)
-
Sound pressure level(SH / H / L) - ㏈(A)
-
41 / 37 / 33
DIMENSIONS (W × H × D)
-
Dimensions(W x H x D) - ㎜
-
1,101 x 405 x 1,230
HEAT EXCHANGER
-
Type
-
Air to Air cross flow heat exchange
NET WEIGHT
-
Net Weight - kg
-
63
POWER SUPPLY
-
Power Supply - Ø , V, Hz
-
1, 220-240, 50
DUCT WORK
-
Qty - EA
-
4
-
Size (Ø) - ㎜
-
Ø 250
SUPPLY AIR FAN
-
Qty - EA
-
1
-
Type
-
Direct-Drive Sirocco
EXHAUST AIR FAN
-
Qty - EA
-
1
-
Type
-
Direct-Drive Sirocco
FILTERS
-
Qty - EA
-
2
-
Type
-
Cleanable fibrous fleeces
-
Size (W x H x D) - ㎜
-
1,148 x 6 x 245
