All Spec
PANEL
-
Screen Size (Inch)
-
165.1cm (65)
-
Panel Technology
-
IPS
-
Back Light Type
-
Direct
-
Aspect Ratio
-
16 : 9
-
Native Resolution
-
3840x2160 (UHD)
-
Refresh Rate
-
60Hz
-
Brightness
-
500nit (Typ.)
-
Dynamic CR
-
1,000,000:1
-
Color Gamut
-
BT709 95%
-
Viewing Angle (H x V)
-
178 x 178
-
Color Depth (Number of Colors)
-
8bits + FRC, 1.07Billion colors
-
Response Time
-
Tr : 8ms / Tf :10ms
-
Surface Treatment (Haze)
-
25%
-
Operation Hours (Hours/Day)
-
24/7
-
Portait / Landscape
-
Yes / Yes
CONNECTIVITY
-
HDMI In
-
Yes(3), 3840x2160@60Hz, HDCP 2.2/1.4
-
DP In
-
Yes(1), 3840x2160@60Hz, HDCP2.2/1.3
-
RS232C In
-
Yes(1), 4pin Phone-jack
-
RJ45(LAN) In
-
Yes(1)
-
IR In
-
Yes(1)
-
USB In
-
USB2.0 Type A(1)
-
HDMI Out
-
Yes(1), 3840x2160@30Hz, Input : HDMI1/2/3/DP
-
Audio Out
-
Yes(1)
-
RS232C Out
-
Yes(1), 4pin Phone-jack
-
Daisy Chain
-
Yes(Input HDMI, DP / Output HDMI)
MECHANICAL SPECIFICATION
-
Bezel Color
-
Black
-
Bezel Width
-
T/R/L/B: 12.4mm(Even)
-
Weight (Head)
-
21.6Kg
-
Packed Weight
-
28.4Kg
-
Monitor Dimensions (W x H x D)
-
1458 x 833 x 57.7mm (Without IR)
-
VESA Standard Mount Interface
-
300 x 300
-
Carton Dimensions (W x H x D)
-
1600 x 970 x 179mm
FEATURE - HARDWARE
-
Internal Memory (eMMC)
-
16GB
-
Wi-Fi/BT (Built-in)
-
Yes
-
Temperature Sensor
-
Yes
-
Auto Brightness Sensor
-
Yes( IR)
-
Acceleration(Gyro) Sensor
-
Yes
-
Local Key Operation
-
Yes
FEATURE - SOFTWARE
-
OS Ver. (webOS)
-
webOS 6.0
-
Local Contents Scheduling
-
Yes
-
Fail Over
-
Yes
-
Booting Logo Image
-
Yes
-
No Signal Image
-
Yes
-
RS232C Sync
-
Yes
-
PIP
-
Yes
-
PBP
-
Yes(4)
-
Screen Share
-
Yes
-
Screen Rotation
-
Yes
-
External Input Rotation
-
Yes
-
Tile Mode Setting
-
Yes (Max. 15x15)
-
SNMP
-
Yes
-
Cisco Certification
-
Yes
-
Smart Energy Saving
-
Yes
-
Wake on LAN
-
Yes
-
BEACON
-
Yes
-
HDMI-CEC
-
Yes
ENVIRONMENT CONDITIONS
-
Operation Temperature
-
0 °C to 40 °C
-
Operation Humidity
-
10 % to 80 %
POWER
-
Power Supply
-
AC 100-240V~, 50/60Hz
-
Power Type
-
Built-In Power
POWER CONSUMPTION
-
BTU (British Thermal Unit)
-
495 BTU/Hr(Typ.), 682 BTU/Hr(Max)
-
Smart Energy Saving (70%)
-
101.5W
-
DPM
-
0.5W
-
Power off
-
0.5W
-
Max.
-
200W
-
Typ.
-
145W
SOUND
-
Speaker (Built-in)
-
Yes
CERTIFICATION
-
Safety
-
CB / NRTL
-
EMC
-
FCC Class "B" / CE / KC
-
ERP / Energy Star
-
Yes (NewErP) / Yes
SOFTWARE COMPATIBILITY
-
SuperSign CMS
-
Yes
-
SuperSign Control+
-
Yes
-
SuperSign WB
-
Yes
-
SuperSign Cloud
-
Yes
-
Mobile CMS
-
Yes
-
Connected Care
-
Yes
LANGUAGE
-
OSD
-
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish→Türkiye, Arabic
ACCESSORY
-
Basic
-
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender
-
Optional
-
Slim Wall Mount (WB21LMA/B), Wall Mount (LSW240A/B) Wall Mount Adapter (AM-B220S)
SPECIAL FEATURE
-
Tilt (Face down)
-
Yes(Max 30° degree, 40°C temperature)
-
IP Rating
-
IP5x
-
Conformal Coating (Power Board)
-
Yes
