Pitch
24mm
LED Type
R, G, B 3in1 Color Package (SMD1818)
Resolution
28 x 20
Pixels per Panel
560
Pixel Density [point/m²]
1,736
Brightness
> 1,000cd/m²
Contrast Ratio
≥ 100,000:1
Luminance Uniformity
≥ 70%
Viewing Angle (H x V)
120 x 120
Life Time (Brightness 50%)
50,000 Hrs
Daily Usage
24 Hrs/7 Days
Adhesion (After Installation)
50,000 Hrs
Transmittance
73%
Operating Temperature
0℃ ~ 45℃ (Indoor Glass Installation Only)
Curved Installation
1,100R (Convex and Concave)
Film Trimming
Yes (Parallel to the Bezel Side Only)
Color Processing
130/120/110 Level (R, G, B)
Colors
1,716,000 Colors
Color Chromaticity
Cx: 0.28±0.03, Cy: 0.28±0.03
Dimension (W x H x D)
668 x 480 x 2.0 mm (with Front & Back Protection Film)
Weight
0.73kg
Power Consumption
37W (Transparent Panel 1ea, Bezel Kit 1ea)
Dimension (W x H x D)
547.3 x 63 x 24 mm
Weight
0.45kg
Dimension (W x H x D)
479.5 x 28.1 x 24 mm
Weight
0.26kg
Dimension (W x H x D)
183 × 86 × 28 mm
Weight
0.769kg
Input
100~240V, 50~60Hz
Output
19.5V/10.8A (210W)
Color
White
DC Output Cable
14AWG, 1.5m
Resolution
960 x 540 (4 Unit Controllers Needed for FHD)
Interface
LVDS In, RJ45 (4ea) Out
Maximum Transmission Length
100m
Dimension (W x H x D)
273 × 186.8 × 37 mm
Weight
1.5kg
Power Consumption
20W
Accessories
Power Cord, LVDS MCX Cable, ESG, Regulation Book, Warranty Card
Video
DP: 3,840 x 2,160 @30Hz
HDMI: 3,840 x 2,160 @30Hz
DVI-D: 1,920 x 1,080 @60Hz
Input
HDMI, DP, DVI-D, RS232C, RJ45 (w/o LED Indicator), IR Receiver (for Installation), USB 3.0
Output
LVDS, DP, RS232C, RJ45 (w/o LED Indicator)
Dimension (W x H x D)
293 x 40.1 x 193.3 mm
Weight (Head)
1.6kg
Temperature Sensor
0
Light Sensor
0
Source Selection
HDMI, DVI-D, DP
TPC
Yes
Power Consumption
17W
CMS S/W
Yes
Accessories
Power Cord, IR & Bright Sensor, 4P Phone-to-RS232C Gender, ESG, Regulation Book, Warranty Card
