All Spec
PHYSICAL PARAMETERS
-
Pixel Configuration
-
3 in 1 SMD
-
Pixel Pitch (mm)
-
1.56
-
Screen Resolution
-
1,920 x 1,080
-
Module Dimensions (WxH,mm)
-
250 x 281.25
-
No. of Modules per Screen (WxH)
-
12 x 6 (Total 72)
-
Screen Dimensions (W x H x D, mm, including bezel)
-
3,004.6 x 1692.1 x 36.5 (Thickest 70)
-
Screen Surface Area (㎡)
-
5.06
-
Weight of the screen
-
129
-
Physical Pixel Density (pixels/㎡)
-
409,600
-
Flatness of Unit Case (mm)
-
±0.2
-
Unit Case material
-
Aluminum
-
Service access
-
Front
OPTICAL SPECIFICATIONS
-
Min. Brightness (After Calibration)
-
500
-
Color Temperature
-
7300K
-
Visual Viewing Angle (H x V)
-
160° x 160°
-
Brightness Uniformity
-
98%
-
Color Uniformity
-
±0.015Cx,Cy
-
Contrast Ratio
-
3000:1
-
Processing Depth (bit)
-
16
ELECTRICAL SPECIFICATIONS
-
Power Consumption (W/Screen, Max.)
-
2,000
-
Power Consumption (W/Screen, Avg.)
-
800
-
Power Consumption (W/㎡, Max.)
-
395
-
Power Consumption (BTU/h/Screen, Max.)
-
6,824
-
Power Consumption (BTU/h/Screen, Avg.)
-
2,730
-
Power Consumption (BTU/h/㎡, Max.)
-
1,348
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50 / 60
-
Refresh Rate (Hz)
-
≥2880
OPERATION SPECIFICATIONS
-
I/O Port
-
HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, SPDIF
-
LED Lifetime (Half brightness)
-
100,000
-
Operating Temperature(℃)
-
0℃ to +40℃
-
Operating Humidity
-
<90%RH (without condensation)
-
IP rating Front
-
IP30
-
IP rating Rear
-
IP20
-
Speaker
-
Built-in (9W+9W)
-
Certification
-
CE,FCC,ETL,CB
-
Environment
-
RoHS, REACH
-
Controller
-
Embedded
