Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.56
Screen Resolution (WxH)
2,560 × 1,080
Module Dimensions (W × H, mm)
250 × 281.25
No. of Modules per Screen (WxH)
16 × 6 (Total 96)
Screen Dimensions (W x H x D, mm)
4,003.3 × 1,691.8 × 36.5 (Thickest 70)
Screen Surface Area (㎡)
6.8
Screen Weight (kg)
176
Physical Pixel Density (pixels/m²)
409,600
Flatness of Cabinet (mm)
±0.2
Cabinet Material
Aluminum
Service access
Front
Brightness (nit)
500
Color Temperature (K)
3,200 - 9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
98%
Color Uniformity
±0.015 Cx, Cy
Contrast Ratio
3,000:1
Processing Depth (bit)
16(HDR10, HDR10 Pro)
Power Consumption (W/Screen, Max.)
2,100
Power Consumption (W/Screen, Avg.)
840
Power Consumption (W/m², Max.)
311
Power Consumption (BTU/h/Screen, Max.)
7,165
Power Consumption (BTU/h/Screen, Avg.)
2,866
Power Consumption (BTU/h/m², Max.)
1,062
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,960
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature (°C)
0 to +40
Operating Humidity
10-90% RH
IP Rating (Front / Rear)
IP30 / IP20
Speaker
Built-in (9 W + 9 W)
Certification
CE,FCC,ETL,CB
Environment
RoHS, REACH
Controller
Embedded
I/O Port
HDMI (3), DP (1), USB, LAN, RS-232C In/Out, IR,
Optical Digital Audio Out
