Pixel Configuration
1R, 1G, 1B (Chip on Board)
Pixel Pitch (mm)
0.938
Module Resolution (W x H)
160 × 180
Module Dimensions (W x H, mm)
150 × 168.8
Weight per Module (kg)
0.15
No. of Modules per Cabinet (W × H)
8 (4 × 2)
Cabinet Resolution (W × H)
640 × 360
Cabinet Dimensions (W × H × D, mm)
600 × 337.5 × 44.9
Cabinet Surface Area (m²)
0.203
Weight per Cabinet (kg/cabinet)
7.0
Weight per Square Meter (kg/m²)
34.6
Physical Pixel Density (pixels/m²)
1,137,778
Flatness of Cabinet (mm)
±0.5
Cabinet Material
Die-casting Aluminum
Service Access
Front and Rear
(Module : Front Only)
Min. Brightness (After Calibration)
Peak 1,200 / Max. 600
Color Temperature
7,300K / 3,200~9,300K
(Adjustable by LED Assistant on PC)
Visual Viewing Angle (H×V)
160° × 160°
Brightness Uniformity
95%
Color Uniformity
±0.02Cx, Cy
Contrast Ratio (10 lux)
150,000 : 1
Processing Depth (bit)
20
HDR Compatibility
HDR10, HDR10 Pro
* LG's own HDR solution to process HDR signal by using enhanced dynamic tone mapping
Power Consumption (W/cabinet, Max.)
125
Power Consumption (W/cabinet, Avg.)
85
Power Consumption (W/m², Max.)
617
Heat Dissipation (BTU/h/Cabinet, Max.)
426
Heat Dissipation (BTU/h/Cabinet, Avg.)
290
Heat Dissipation (BTU/h/m², Max.)
2,105
Power Supply (V)
100 to 240
Frame Rate (Hz)
50/60
Refresh Rate (Hz)
3,840
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature(℃)
0∘ to +40∘
Operating Humidity
10-80%RH
IP Rating (Front / Rear)
IP50 / IP20
Certification
Safety 60950-1,
EMC Class A,
BS476 Part7 Class1
Environment
RoHS
Controller
CSAB-009X
