Pixel Configuration
COB
Pixel Pitch (mm)
1.25
Module Resolution (W x H)
240 × 90
Module Dimensions (W x H, mm)
300 ×112.5
Weight per Module (kg)
0.18
No. of Modules per Cabinet (W × H)
2 × 3
Cabinet Resolution (W × H)
480 × 270
Cabinet Dimensions (W × H × D, mm)
600 × 337.5 × 44.9
Cabinet Surface Area (m²)
0.203
Weight per Cabinet (kg/cabinet)
7.2
Weight per Square Meter (kg/m²)
35.5
Physical Pixel Density (pixels/m²)
640,000
Flatness of Cabinet (mm)
±0.5
Cabinet Material
Die-casting Aluminum
Service Access
Front
Min. Brightness (After Calibration)
1,600 / 800(Peak)
Color Temperature
3,200-9,300 (Default 7,300)
Visual Viewing Angle (H×V)
160° × 160°
Brightness Uniformity
95%
Color Uniformity
±0.02Cx, Cy
Contrast Ratio (10 lux)
150,000 : 1 @ 10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
HDR Compatibility
HDR10, HDR10 Pro
* LG's own HDR solution to process HDR signal by using enhanced dynamic tone mapping
Power Consumption (W/cabinet, Max.)
82
Power Consumption (W/cabinet, Avg.)
50
Power Consumption (W/m², Max.)
405
Heat Dissipation (BTU/h/Cabinet, Max.)
280
Heat Dissipation (BTU/h/Cabinet, Avg.)
171
Heat Dissipation (BTU/h/m², Max.)
1,385
Power Supply (V)
100 to 240
Frame Rate (Hz)
50/60
Refresh Rate (Hz)
3,840
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature(℃)
0∘ to +40∘
Operating Humidity
10-80%RH
IP Rating (Front / Rear)
IP50 / IP20
Certification
Safety 60950-1, EMC Class B
BS476 Part7 Class1
Environment
RoHS
Controller
CSAB-0121
