Pixel Configuration
3 in 1
Pixel Pitch(mm)
1.250
Module Resolution (WxH)
240x135
Module Dimensions(WxH,mm)
300x168.75
Weight per Module (kg)
0.37 (-RK,-CK)/ 0.67 (-CKF)
No. of Modules per Cabinet (WxH)
2x2 (-RK)/ 1x2 (-CK,-CKF)
Cabinet Resolution (WxH)
480x270 (-RK)/ 240x270 (-CK, -CKF)
Cabinet Dimensions (W x H x D, mm)
600x337.5x34 (-RK)/
300x337.5x29.7 (-CK)/
300x337.5x35.6 (-CKF, Cabinet Mounting Depth)
Cabinet Surface Area (㎡)
0.203 (-RK)/ 0.101 (-CK, -CKF)
Weight per Cabinet (kg/unit)
5.3 (-RK)/ 4.0 (-CK)/
3.5 (-CKF, Weight Changes for Different Curves)
Weight per Square Meter (kg/m²)
26.2 (-RK)/ 39.0 (-CK)/ 34.6 (-CKF)
Physical Pixel Density (pixels/m²)
640,000
Flatness of Cabinet (mm)
±0.1
Cabinet Material
Die-casting Aluminum (-RK)/
Aluminum Machine (-CK, CKF)
Service Access
Front
Max Brightness (After Calibration, nit)
800
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (H×V)
160 × 160
Brightness Uniformity
97%
Color Uniformity
±0.003CxCy
Contrast Ratio
5,000:1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
Power Consumption (W/cabinet, Max.)
150 (-RK)/ 75 (-CK, -CKF)
Power Consumption (W/cabinet, Avg.)
50 (-RK)/ 25 (-CK, CKF)
Power Consumption (W/㎡, Max.)
740
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Hours to Half Brightness)
100,000
Operating Temperature(℃)
-10∘to +45∘
Operating Humidity
0~80%RH
IP Rating (Front / Rear)
IP30 / IP30
Controller
CVCA
90 Degree Corner Cut
Yes
