Cabinet Dimensions (W x H x D, mm)
3,004 × 1,742 × 54.9
Cabinet material
Steel
Flatness of Cabinet (mm)
±0.2
Module Dimensions(WxH,mm)
300 x 112.5
Module Resolution (WxH)
384 x 144
No. of Modules per Cabinet (WxH)
10 × 15 (Total 150)
Physical Pixel Density (pixels/㎡)
1638400
Pixel Configuration
Micro
Pixel Pitch (mm)
0.78
Screen Dimensions (W x H x D, mm, including bezel)
3,004 × 1,742 × 54.9 (Thickest 57.4)
Screen Resolution (WxH)
3840 x 2160
Screen Surface Area (㎡)
5.06
Service access
Front
Weight of the screen (kg)
190
Brightness Uniformity(%)
95 %
Color Temperature
3,200-9,300
Color Temperature (K)
3,200-9,300
Color Uniformity
±0.015 Cx, Cy
Contrast Ratio
25,000 : 1 @ 10 lux
Max Brightness (After Calibration, nit)
500 / (Peak.) 1,000
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Frame Rate (Hz)
50 / 60
Heat Dissipation (BTU/h/Screen, Avg.)
2,900
Heat Dissipation (BTU/h/Screen, Max.)
4,950
Power Consumption (W/㎡, Max.)
277
Power Consumption (W/Screen, Avg.)
850
Power Consumption (W/Screen, Max.)
1,450
Power Supply (V)
100 to 240
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
IP rating Front
IP50
IP rating Rear
IP20
Operating Humidity
10~80 % RH
Operating Temperature(℃)
0 ℃ to +40 ℃
Certification
FCC, CE CB, BS476 Part7 Class1
Speaker
Built-in(10 W+10 W)
Environment
RoHS
Controller
Embedded(webOS)
I/O Port
HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, Optical Digital Audio Out
Model name
LAAA007-G2
