Pixel Configuration
Micro
Pixel Pitch (mm)
0.9375
Module Resolution (W x H)
320 × 120
Module Dimensions (W x H, mm)
300 × 112.5
Weight per Module (kg)
0.19
No. of Modules per Cabinet (W × H)
2 × 3
Cabinet Resolution (W × H)
640 × 360
Cabinet Dimensions (W x H x D, mm)
600 x 337.5 x 44.9
Cabinet Surface Area (m²)
0.203
Weight per Cabinet (kg/unit)
6.4
Weight per Square Meter (kg/m²)
31.6
Physical Pixel Density (pixels/m²)
1,137,778
Flatness of Cabinet (mm)
±0.5
Cabinet Material
Extrusion Aluminum
Service Access
Front and Rear
* Module can be accessed only from the front
Max Brightness (After Calibration, nit)
600 / Peak 1,200
Color Temperature (K)
3,200~9,300 / Default 7,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
95%
Color Uniformity
±0.02Cx,Cy
Contrast Ratio
100,000:1 @10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Power Consumption (W/cabinet, Max.)
67
Power Consumption (W/cabinet, Avg.)
40
Power Consumption (W/m², Max.)
331
Heat Dissipation (BTU/h/Cabinet, Max.)
229
Heat Dissipation (BTU/h/Cabinet, Avg.)
137
Heat Dissipation (BTU/h/m², Max.)
1,132
Power Supply (V)
48 Vdc
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0℃ to +40℃
Operating Humidity
10-80%RH
IP rating Front
IP50
IP rating Rear
IP20
Certification
Safety 60950-1,
EMC Class B,
BS476 Part7 Class1
Environment
RoHS
Controller
CSAB-00915D
