Tutte le specifiche
DIMENSIONI
-
Unità esterna (L × A × P) (mm)
-
1239x1380x330
ESTERNO
-
Unità esterna (codice colore / RAL)
-
Grigio seta / RAL 7044
CAPACITÀ NOMINALE E COP (A-7/W+35)
-
COP
-
3,34
-
Prestazioni di riscaldamento (kW)
-
14,00
CAPACITÀ NOMINALE E COP (A-7/W+55)
-
COP
-
2,47
-
Prestazioni di riscaldamento (kW)
-
14,00
CAPACITÀ NOMINALE E COP (A+2/W+35)
-
COP
-
4,28
-
Prestazioni di riscaldamento (kW)
-
14,00
CAPACITÀ NOMINALE E COP (A+7/W+35)
-
COP
-
4,80
-
Prestazioni di riscaldamento (kW)
-
14,00
CAPACITÀ NOMINALE E COP (A+7/W+55)
-
COP
-
3,40
-
Prestazioni di riscaldamento (kW)
-
14,00
CAPACITÀ NOMINALE ED EER (A+35/W+18)
-
Prestazioni di raffreddamento (kW)
-
14,00
-
EER
-
4,30
CAPACITÀ NOMINALE ED EER (A+35/W+7)
-
Prestazioni di raffreddamento (kW)
-
14,00
-
EER
-
3,30
GAMMA DI FUNZIONAMENTO (TEMPERATURA DELL’ACQUA IN USCITA)
-
Raffreddamento (Min. ~ Max.) (℃)
-
5 ~ 27
-
DHW (Min. ~ Max.) (℃)
-
15 ~ 80
-
Riscaldamento (Min. ~ Max.) (℃)
-
15 ~ 65
GAMMA DI FUNZIONAMENTO (TEMPERATURA DELL’ARIA ESTERNA)
-
Raffreddamento (Min. ~ Max.) (℃)
-
5 ~ 48
-
Riscaldamento e DHW (min. ~ max.) (℃)
-
-25 ~ 35
COLLEGAMENTI DELLE TUBAZIONI (ACQUA/UNITÀ ESTERNA)
-
Diametro di ingresso (pollici)
-
M 1"
ALIMENTAZIONE
-
Tensione, fase, frequenza per unità esterna (V, Ø, Hz)
-
380-415, 3, 50
REFRIGERANTE
-
PRG
-
675
-
Quantità precaricata (g)
-
2
-
Tipo
-
R32
DATI SULL’EFFICIENZA STAGIONALE (RISCALDAMENTO)
-
SCOP (35℃ / 55℃)
-
4,62 / 3,46
-
Efficienza stagionale per il riscaldamento degli ambienti (ηS) (35℃ / 55℃)
-
182% / 135%
-
Classe di efficienza stagionale per il riscaldamento degli ambienti (35℃ / 55℃)
-
A+++ / A++
LIVELLO DI PRESSIONE SONORA A 5M (UNITÀ ESTERNA, CONVERSIONE UTILIZZANDO SWL)
-
Modalità nominale/a basso rumore (dB(A))
-
61 / 57
PESO
-
Unità esterna (Vuoto) (kg)
-
118,6
INFORMAZIONI DI CONFORMITÀ
