75XF3C-B component-copyModelName
75'' 3,000nits UHD Open-frame Display

Key Features

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (75XF3C-B)
    $
    $
    LG Members Price
Total
Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (75XF3C-B)
    $
    $
    LG Members Price
Total
75" 3,000nits UHD Open-frame Display

Advanced Reliability with Enhanced Brightness

In front of the burger drive-thru store, there is an XF3C-B installed, displaying burger menus and other advertisements. In front of the burger drive-thru store, there is an XF3C-B installed, displaying burger menus and other advertisements.
* All images in this page are for illustrative purposes only.

High Visibility
Under Strong Sunlight

With a brightness of 3,000 nits, 75XF3C-B boasts high visibility in bright environments. In addition, its clear visibility can deliver a variety of information even to those wearing polarized sunglasses.
A large-sized display is installed on the street, and women are looking at a vivid-quality advertisement on the screen. A large-sized display is installed on the street, and women are looking at a vivid-quality advertisement on the screen.
A blurry picture of FHD is being compared with UHD with vivid quality images. A blurry picture of FHD is being compared with UHD with vivid quality images.

Superb Picture Quality with Ultra HD Resolution

With the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents.

* Within 178 degree
A display is working well in an environment of 0~50°C. A display is working well in an environment of 0~50°C.

Wide Range of Operating Temperature

75XF3C-B can be used under a wide range of operating temperatures from 0°C to +50°C.
The XF3C-B has a conformal coating making it resistant to dust and salinity in moisture. The XF3C-B has a conformal coating making it resistant to dust and salinity in moisture.

Conformal Coating

Conformal Coating* protect the circuit board, power board against dust, iron powder, humidity, etc.

* Thin protective films/breathing membranes that filter water vapor and solid debris
M+ panels reduce power consumption by 35% compared to RGB. M+ panels reduce power consumption by 35% compared to RGB.

Low Power Consumption Using the M+ Panel

The M+ panel can offer high energy efficiency and cost savings as decreasing power consumption by approx.

* M+ IPS reduced approx. by 35% BLU Power consumption (IEC62087, 10 min) compared to RGB IPS, tested under same brightness (@fullwhite, 400 nit)
** Specific features can differ from circumstances.

Smart Brightness Control

The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
The XF3C-B screen can adjust its brightness automatically according to the ambient light. The XF3C-B screen can adjust its brightness automatically according to the ambient light.
It has improved user convenience by utilizing the SoC and webOS. It has improved user convenience by utilizing the SoC and webOS.

webOS Smart Platform

Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 3.0 platform enhances user convenience with intuitive UI and simple app development tools.
User can monitor and control their displays through mobile phone and laptop. User can monitor and control their displays through mobile phone and laptop.

Web Monitoring

The LG Control Manager*, the embedded web monitoring program, allows a variety of parameters to be diagnosed in real time such as temperature, ambient light, and gyro sensors. It can be easily controlled at all times.

* Enabled by wired LAN connection
Close
PANEL
  • Screen Size
    75" Class
    Resolution
    3,840 x 2,160 (UHD)
  • Brightness (Typ., cd/m²)
    3000
CONNECTIVITY
  • Input
    HDMI(2), DP, DVI-D, Audio, USB, SD Card
    Output
    DP, External Speaker Out (L/R)
  • External Control
    RS232C In/Out, RJ45 In, IR Receiver In
PHYSICAL SPECIFICATION
  • Bezel Width
    11.8 mm (Even)
    Monitor Dimension (W x H x D)
    1,675.2 x 953.6 x 123.9 mm
  • Weight (Head)
    36.7 kg
    Carton Dimensions (W x H x D)
    1,816 x 1,106 x 285 mm
  • Packed Weight
    46.3 kg
ENVIRONMENT CONDITIONS
  • Operation Temperature
    0℃ to 50℃ (w/o Direct Sunlight, Direct Sunlight in Cooling System),
    0℃ to 40℃ (Direct Sunlight)
    Operation Humidity
    10% to 85%
POWER
  • Power Supply
    100-240 V~, 50/60 Hz
    Power Type
    Built-In Power
POWER CONSUMPTION
  • Typ.
    660W (Full White)
    403W (IEC 62087)
    Max
    695W
STANDARD(CERTIFICATION)
  • Safety
    UL recognized / CB
    EMC
    FCC Class "A" / CE / KC
  • ErP / Energy Star
    No / No
SOFTWARE COMPATIBILITY
  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control+ / Control
ACCESSORY
  • Basic
    Remote Controller, Power Cord, IR Extension Kit, HDMI Cable, Manual (ESG&EIG)
    Optional
    Wi-Fi Dongle (AN-WF500)
COMPLIANCE INFORMATION
  • component-safetyInformationNotice-en
  • component-safetyInformationNotice-locale
