![Black line drawing of a compressor with a red speedometer needle indicating high speed.]()
Exceptional Performance
The LG Inverter Single Package does not require additional installation to provide both heating and cooling. The compressor adjusts its output according to the surroundings, reducing the energy costs1) and maximizing energy efficiency.
-
![A fan blade with two curved arrows circling it, indicating continuous rotation, and a red checkmark below.]()
Direct Drive Motor for Convenience
The Direct Drive Fan Motor has high static pressure, offering a wide range of E.S.P. coverage. It is convenient to manage as it does not require regular greasing, and the RPM is adjustable via remote control.
-
![A cogwheel with a red wrench inside it and a red checkmark in the center.]()
Easy Installation & Maintenance
The LG Single Package is designed for easy installation and maintenance, featuring convenient hinged doors for easy access and a Black Fin heat exchanger, optimized for performance in corrosive environments.
-
![A remote control with buttons for power, arrows, and a circular button. The screen displays "ESP" in red.]()
Intuitive Control
The LG Inverter Single Package controller features an intuitive GUI and supports managing up to 16 units with Group Control.2) It is also compatible with gateways supporting various protocols.
2. The maximum capacity may vary depending on regional specifications.
-
- Case 1
- 380-400-415, 3, 50/60
- Limit Range of Voltage (V)
- 342 ~ 456 V
-
- Nominal Capacity (RT)
- 7.5
-
- Net(Min ~ Rated ~ Max) (kW)
- 14.00~26.40~34.60
- Net(Min ~ Rated ~ Max) (kcal/h)
- 12,020~22,680~29,740
-
- Net(Min ~ Rated ~ Max) (Btu/h)
- 47,700~90,000~118,000
- Gross(Min ~ Rated ~ Max) (kW)
- 14.50~27.00~35.20
-
- Gross(Min ~ Rated ~ Max) (kcal/h)
- 12,500~23,170~30,230
- Gross(Min ~ Rated ~ Max) (Btu/h)
- 49,600~91,960~119,960
-
- Net(Min ~ Rated ~ Max) (kW)
- 14.00~26.40~34.60
- Net(Min ~ Rated ~ Max) (kcal/h)
- 12,020 ~ 22,680 ~ 29,740
-
- Net(Min ~ Rated ~ Max) (Btu/h)
- 47,700 ~ 90,000 ~ 118,000
-
- Cooling(Min ~ Rated ~ Max) (kW)
- 2.30~7.37~15.00
- Heating(Min ~ Rated ~ Max) (kW)
- 2.30~7.13~15.00
-
- EER (Btu / Wh)
- 12.2
- IEER (Btu / Wh)
- 20
-
- COP (W/W)
- 3.7
-
- Type
- Propeller Fan
- Diameter (mm(inch))
- 680(26-25/32)
-
- Air Flow Rate(Nominal) (㎥/min x No.)
- 105 x 1
- Discharge direction
- Top
-
- Drive
- BLDC Inverter
- Output (W x No.)
- 1,500 x 1
-
- Type
- Plug Fan
- Diameter (mm(inch))
- 560 (22)
-
- Air Flow Rate(Nominal) (㎥/min)
- 85
-
- Drive
- BLDC Inverter
- Output (HP x No.)
- 10 x 1
-
- No. (EA)
- 1
- Size(W x H x D) (inch)
- 40 X 40 X 0.28
-
- No. (EA)
- 4
- Size(W x H x D) (inch)
- 20 X 20 X 2
-
- Type
- HSS DC SCROLL
- Motor Output (W x No.)
- 5,500 x 1
-
- Oil Type
- FW68D(PVE)
- Oil Charging amount (cc x No.)
- 1,500 x 1
-
- Rows x Columns x FPI
- (3 x 52 x 14) x 1
- Fin Type
- Wide Louver Plus
-
- Tube size(Outer Dia.) (mm(inch))
- 7(9/32)
- Face Area (㎡)
- 2.4
-
- Rows x Columns x FPI
- (4 × 22 × 16) × 2
- Fin Type
- LG Louver
-
- Tube size(Outer Dia.) (mm(inch))
- 9.52(3/8)
- Face Area (㎡)
- 1.01
-
- Net(W x H x D) (mm)
- 1,130 x 1,242 x 2,250
- Shipping(W x H x D) (mm)
- 1,150 x 1,270 x 2,270
-
- Net (kg)
- 440
- Shipping (kg)
- 460
-
- Type
- R410A
- Precharged Amount(A-Circuit) (kg)
- 9
-
- Control Type
- EEV
-
- Dehumidification Rate (ℓ/h)
- 9.1
-
- Drain Connection Size (inch)
- Male NPT 3/4"
-
- Cooling / Heating (dB(A))
- 80.0 / 80.0
-
- Minimium Circuit Amperes (MCA) (A)
- 43
- Maximum Fuse Amperes (MFA) (A)
- 50
-
- Comp_Rated Load Amperes (A)
- 28.8
- Outdoor Fan Motor_Full Load Amperes (FLA) (A)
- 3
-
- Indoor Fan Motor_Full Load Amperes (FLA) (A)
- 4
