AK-W240LH00 ADGGDXB component-copyModelName
Single Package, S.PKG_Set (1Φ), 24kBtu

Key Features

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (AK-W240LH00 ADGGDXB)
    $
    $
    LG Members Price
Total
Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (AK-W240LH00 ADGGDXB)
    $
    $
    LG Members Price
Total
Single Package, S.PKG_Set (1Φ), 24kBtu
  • Black line drawing of a compressor with a red speedometer needle indicating high speed.

    Exceptional Performance

    The LG Inverter Single Package does not require additional installation to provide both heating and cooling. The compressor adjusts its output according to the surroundings, reducing the energy costs1) and maximizing energy efficiency.

  • A fan blade with two curved arrows circling it, indicating continuous rotation, and a red checkmark below.

    Direct Drive Motor for Convenience

    The Direct Drive Fan Motor has high static pressure, offering a wide range of E.S.P. coverage. It is convenient to manage as it does not require regular greasing, and the RPM is adjustable via remote control.

  • A cogwheel with a red wrench inside it and a red checkmark in the center.

    Easy Installation & Maintenance

    The LG Single Package is designed for easy installation and maintenance, featuring convenient hinged doors for easy access and a Black Fin heat exchanger, optimized for performance in corrosive environments.

  • A remote control with buttons for power, arrows, and a circular button. The screen displays "ESP" in red.

    Intuitive Control

    The LG Inverter Single Package controller features an intuitive GUI and supports managing up to 16 units with Group Control.2) It is also compatible with gateways supporting various protocols.

1. The cost may vary depending on the environment and region.
2. The maximum capacity may vary depending on regional specifications.
Close
Power Supply
  • Case 1
    380-400-415, 3, 50/60
    Limit Range of Voltage (V)
    342 ~ 456 V
Nominal Capacity
  • Nominal Capacity (RT)
    20
Cooling Capacity
  • Net(Min ~ Rated ~ Max) (kW)
    30.50~70.00~90.30
    Net(Min ~ Rated ~ Max) (kcal/h)
    26,210~60,480~77,610
  • Net(Min ~ Rated ~ Max) (Btu/h)
    104,000~240,000~308,000
    Gross(Min ~ Rated ~ Max) (kW)
    32.50~72.30~92.30
  • Gross(Min ~ Rated ~ Max) (kcal/h)
    27,950~62,220~79,350
    Gross(Min ~ Rated ~ Max) (Btu/h)
    110,900~246,900~314,900
Heating Capacity
  • Net(Min ~ Rated ~ Max) (kW)
    30.50~70.30~90.30
    Net(Min ~ Rated ~ Max) (kcal/h)
    26,210~60,480~77,610
  • Net(Min ~ Rated ~ Max) (Btu/h)
    104,000~240,000~308,000
Power Input
  • Cooling(Min ~ Rated ~ Max) (kW)
    11.90~21.30~32.10
    Heating(Min ~ Rated ~ Max) (kW)
    11.60~20.80~31.40
Efficiency
  • EER (Btu / Wh)
    11.3
    IEER (Btu / Wh)
    19
  • COP (W/W)
    3.38
Outdoor Fan
  • Type
    Propeller Fan
    Diameter (mm(inch))
    680(26-25/32)
  • Air Flow Rate(Nominal) (㎥/min x No.)
    105 x 4
    Discharge direction
    Top
Outdoor Fan Motor
  • Drive
    BLDC Inverter
    Output (W x No.)
    900 x 4
Indoor Fan
  • Type
    Plug Fan
    Diameter (mm(inch))
    630(25)
  • Air Flow Rate(Nominal) (㎥/min)
    227
Indoor Fan Motor
  • Drive
    BLDC Inverter
    Output (HP x No.)
    10 x 1
Pre-Filter(Washable)
  • No. (EA)
    2
    Size(W x H x D) (inch)
    75 X 20 X 0.28
2'' Filter(Field Acc.)
  • No. (EA)
    6
    Size(W x H x D) (inch)
    25 X 20 X 2
Compressor(#1, A Cycle)
  • Type
    HSS DC SCROLL
    Motor Output (W x No.)
    5,500 x 1
  • Oil Type
    FW68D(PVE)
    Oil Charging amount (cc x No.)
    1,500 x 1
Compressor(#2, B Cycle)
  • Type
    HSS DC SCROLL
    Motor Output (W x No.)
    5,500 x 1
  • Oil Type
    FW68D(PVE)
    Oil Charging amount (cc x No.)
    1,500 x 1
Outdoor Coil
  • Rows x Columns x FPI
    (3 x 52 x 14) x 1
    Fin Type
    Wide Louver Plus
  • Tube size(Outer Dia.) (mm(inch))
    7(9/32)
    Face Area (㎡)
    4.5
Indoor Coil
  • Rows x Columns x FPI
    (4×44×16)×2
    Fin Type
    LG Louver
  • Tube size(Outer Dia.) (mm(inch))
    9.52(3/8)
    Face Area (㎡)
    2.01
Dimensions
  • Net(W x H x D) (mm)
    2,230 x 1,242 x 3,520
    Shipping(W x H x D) (mm)
    2,250 x 1,270 x 3,560
Weight
  • Net (kg)
    940
    Shipping (kg)
    965
Refrigerant
  • Type
    R410A
    Precharged Amount(A-Circuit) (kg)
    9
  • Precharged Amount(B-Circuit) (kg)
    9
    Control Type
    EEV
Dehumidification Rate
  • Dehumidification Rate (ℓ/h)
    24.1
Drain Connection Size
  • Drain Connection Size (inch)
    Male NPT 1"
Sound Pressure Level
  • Cooling / Heating (dB(A))
    77.0 / 77.0
Electrical Characteristic
  • Minimium Circuit Amperes (MCA) (A)
    88
    Maximum Fuse Amperes (MFA) (A)
    100
  • Comp_Rated Load Amperes (A)
    58.8
    Outdoor Fan Motor_Full Load Amperes (FLA) (A)
    8
  • Indoor Fan Motor_Full Load Amperes (FLA) (A)
    6.5
