Screen Size (Inch)
86
Panel Technology
IPS
Back Light Type
Direct
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
60Hz
Brightness
390nit (Typ., without Glass)
Contrast Ratio
1,200:1
Dynamic CR
NO
Color Gamut
NTSC 68%
Viewing Angle (H x V)
178º x 178º
Color Depth (Number of Colors)
1.07 Billion colors
Response Time
8ms (G to G)
Surface Treatment (Haze)
Haze 28%
Life time
30,000Hrs (Min.)
Operation Hours (Hours/Day)
16/7
Portait / Landscape
NO / YES
HDMI In
YES (3ea)
HDMI In (HDCP Ver.)
2.2/1.4
DP In
NO
DVI-D In
NO
RGB In
YES
Audio In
YES
RS232C In
YES
RJ45(LAN) In
YES (1ea)
IR In
NO
USB In
USB3.0 Type A (3ea), USB2.0 Type A (3ea)
HDMI Out
NO
DP Out
NO
Audio Out
YES
Touch USB
USB2.0 Type B (2ea)
External Speaker Out
NO
RS232C Out
NO
RJ45(LAN) Out
NO
Bezel Color
Black
Bezel Width
T/R/L/B : 18.9/18.9/18.9/45.7mm
Weight (Head)
67.5Kg
Packed Weight
86.6Kg
Monitor Dimensions (W x H x D)
1957 x 1160 x 87mm
Carton Dimensions (W x H x D)
1863 x 1283 x 280mm
Handle
YES
VESA Standard Mount Interface
800 x 600 mm
Internal Memory (eMMC)
32GB
Wi-Fi/BT (Built-in)
YES
Temperature Sensor
NO
Auto Brightness Sensor
NO
Power Indicator
YES
Local Key Operation
YES
Booting Logo Image
YES
PIP
NO
PBP
NO
Screen Share
YES
Setting Data Cloning
NO
Crestron Connected
NO
Smart Energy Saving
NO
PM mode
NO
Wake on LAN
NO
Network Ready
NO
HDMI-CEC
YES
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-in Power
Typ.
370W
Max.
500W
BTU (British Thermal Unit)
1262 BTU/Hr(Typ.), 1706 BTU/Hr(Max.)
DPM
0.5W
Power off
0.5W
Speaker (Built-in)
YES (10W x 2)
Safety
CB / NRTL
EMC
FCC Class "A" / CE
ERP / Energy Star
YES / NO
OPS Type compatible
YES (Slot)
OPS Power Built-in
YES
Connected Care
NO
OSD
English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Russian, Spanish, Swedish, Türkçe, Ukrainian, Traditional Chinese, Hungarian
Basic
Power Cord 3M*1, USB Cable (Type A-Type B) 5M*1, HDMI Cable 3M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional
NO
Conformal Coating (Power Board)
YES
Available Object Size for Touch
Ø3 mm ↑
Response Time ('Paint' app on Windows 10 PC)
10ms ↓
Accuracy (Typ.)
±2.0mm
Interface
USB2.0
Protection Glass Thickness
4mm (Anti-Glare)
Protection Glass Transmission
0.87
Operating System Support
Windows 7/8/10/XP/Linux/Mac/Android (Windows XP/Linux/Mac Support one point touch)
Multi Touch Point
Max. 20 Points
CPU
Dual core A73+Dual core A53
GPU
Dual Core Mail G51
Memory(RAM)
3GB
Storage
32GB
Wi-Fi
802.11a/b/g/n/ac
LAN
Gigabit LAN
Bluetooth
Bluetooth 4.0
OS ver. (Android)
Android 8
