Model name
LAEC018-GN2
Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.88
Module Resolution (WxH)
1,920x1,080
Module Dimensions(WxH,mm)
300x168.75
Physical Pixel Density (pixels/㎡)
284,444
Flatness of Cabinet (mm)
±0.2
Cabinet material
Aluminum
Service access
Front
No. of Modules per Screen (WxH)
12x12 (Total 144)
Screen Resolution (WxH)
1,920x1,080
Screen Dimensions (W x H x D, mm, including bezel)
3,604x2,029x45.5 (Thickest 81)
Screen Surface Area (㎡)
7.29
Weight of the screen
190
Max Brightness (After Calibration, nit)
500
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
0.98
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3,000:1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Color Temperature
3,200~9,300
Power Consumption (W/㎡, Max.)
302
Heat Dissipation (BTU/h/㎡, Max.)
1,030
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,000
Power Consumption (W/Screen, Max.)
2,200
Power Consumption (W/Screen, Avg.)
880
Heat Dissipation (BTU/h/Screen, Max.)
7,506
Heat Dissipation (BTU/h/Screen, Avg.)
3,004
Operating Temperature(℃)
0℃ to +40℃
Operating Humidity
10~90%RH
IP rating Front
IP30
IP rating Rear
IP20
LED Lifetime (Half brightness)
100,000
Certification
CE,FCC,ETL,CB,CE-RED
Environment
RoHS, REACH
Controller
Embedded(webOS)
Speaker
Built-in(9W+9W)
I/O Port
HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, Optical Digital Audio Out
