Screen Size
75"
Panel Technology
IPS
Aspect Ratio
16 : 9
Native Resolution
3,840 x 2,160 (UHD)
Brightness*
500 cd/m² (410 cd/m² w/Protection Glass)
Viewing Angle (H x V)
178 × 178
Input
HDMI (3), DP, DVI-D, RGB, Audio, USB 3.0, USB 2.0, OPS USB 2.0
Output
Touch USB 2.0 (2)
External Control
RS232C In/out, RJ45 In
Bezel Width
41.6 mm(T/L/R/B)
Monitor Dimension (W x H x D)
1,732.8 x 1011.1 x 69.7 mm (w/o Handle)
Weight (head)
74.5 kg
Carton Dimensions (W x H x D)
1,870 x 1,264 x 285 mm(with pallet)
Packed Weight
94 kg
VESA™ Standard Mount Interface
600 x 400 mm
KEY FEATURES
webOS 3.0+, Embedded IDB App, Crestron Connected® (Network Based Control), Mirroring, Soft AP, Beacon, Reader Mode, Auto Brightness Sensor, Internal Memory 64GB(System 8GB for TC3D and 4GB for TR3E)
Special features
Temperature Sensor, ISM Method, DPM Select, Brightness Control, PM Mode, Wake on LAN, Energy Saving, File Play with USB, 2 PIP/PBP, Built-in Wi-Fi (802.11n Combo), USB Cloning, Failover, No Signal Image
Operation Temperature Range
0°C to 40°C
Operation Humidity Range
10% to 80%
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption - Typ.
≤ 240 W
Power Consumption-Smart Energy Saving
≤ 170 W
Power Consumption - DPM
≤ 0.5 W
Built-in Speker
20 W (10W×2)
Safety
AS/NZS 60950,CB Scheme
EMC
AS/NZS CISPR32,RCM(Class A)
OPS Type Compatible
Yes
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/Control +
Basic
Remote Controller (2 BatteriesIncluded), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Eyebolt (2ea, 86TR3E Only), Touch Pen Tip (1ea, TC3D Only)
Optional
OPS Kit (KT-OPSA), Wall Mount (LSW640A/B)
Touch Type
P-Cap (Ag Metal Mesh)
Available Object Size for Touch
more than Ø 6 mm
Accuracy
2 mm
Interface
USB 2.0
Protection Glass Thickness
4T (Anti-glare)
Multi Touch Point
Max. 40 Points (Supported by Windows Application, Max 10 Points for WebOS)
