UM3C Series

Specs

Support

Resource

UM3C Series

Share this content.

You can share the items you like with your friends

UM3C Series

86UM3C-B
()
  • LG UM3C Series, 86UM3C-B
  • LG UM3C Series, 86UM3C-B
  • LG UM3C Series, 86UM3C-B
  • LG UM3C Series, 86UM3C-B
  • LG UM3C Series, 86UM3C-B
  • LG UM3C Series, 86UM3C-B
  • LG UM3C Series, 86UM3C-B
  • LG UM3C Series, 86UM3C-B
LG UM3C Series, 86UM3C-B
LG UM3C Series, 86UM3C-B
LG UM3C Series, 86UM3C-B
LG UM3C Series, 86UM3C-B
LG UM3C Series, 86UM3C-B
LG UM3C Series, 86UM3C-B
LG UM3C Series, 86UM3C-B
LG UM3C Series, 86UM3C-B

Key Features

  • Brightness : 350cd/m²
  • Bezel : 14.3 mm Even Bezel
  • Depth : 60.6mm(without logo/handle)
  • Interface : DP / HDMI / DVI / RS232C / RJ45 / Pixel Sensor / SD Card / USB
More
Print

All Spec

PANEL

  • Screen Size

    86"

  • Panel Technology

    IPS

  • Aspect Ratio

    16 : 9

  • Native Resolution

    3,840 x 2,160 (UHD)

  • Brightness

    350 cd/m²

  • Contrast Ratio

    1,200:1

  • Dynamic CR

    4,000,000:1

  • Viewing Angle (H x V)

    178 × 178

  • Guaranteed Operating Hour

    24 hrs / 7 days

CONNECTIVITY

  • Input

    HDMI, DP, DVI-D, Audio, USB 3.0, SD Card

  • Output

    DP, Audio

  • External Control

    RS232C, RJ45, IR Receiver,Pixel Sensor

PHYSICAL SPECIFICATION

  • Bezel Width

    14.3 mm

  • Monitor Dimension (W x H x D)

    1,926.2 x 1,097.2 x 60.6 mm

  • Weight (head)

    49 kg

  • Carton Dimensions (W x H x D)

    2,073 x 1,260 x 292 mm

  • Packed Weight

    61.1 kg

  • VESA™ Standard Mount Interface

    600 x 400 mm

ENVIRONMENT

  • Operation Temperature Range

    0°C to 40°C

  • Operation Humidity Range

    10% to 80%

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Consumption (Typical)

    160W

  • Power Consumption (Smart Energy Saving)

    115W

STANDARD(CERTIFICATION)

  • Safety

    AS/NZS 60950, CB Scheme

  • EMC

    AS/NZS CISPR32, RCM (Class A)

  • Energy Rating

    Star 7.0 (under 60" models)

MEDIA PLAYER COMPATIBILITY

  • OPS Type Compatible

    Yes

  • External Media Player Attachable

    Yes (MP500/MP700)

SOFTWARE COMPATIBILITY

  • SuperSign Lite/W

    Yes

  • SuperSign C

    Yes

ACCESSORIES

  • Basic

    Remote Controller (include battery 2 ea), Power Cord, QSG, DP Cable Regulation Book, Phone to RS232C Gender, Memory Cover

  • Optional

    Pixel sensor (KT-SP0),Media player, OPS Kit (KT-OPSA),HD Base T (EB-B100) LSW640A/B (Wall Mount)-Speaker (SP-5200), Pixel sensor(KT-SP0), Media player, Wall bracket(LSW350B), VESA Adapter (AMB330S),OPS Kit (KT-OPSA),HD Base T (EB-B100)

To access more technical documentation and resources, please visit the LG B2B partner portal.
