Fine-pitch Essential Series
All Spec
PHYSICAL PARAMETER
-
Pixel Configuration
3 in 1
-
Pixel Pitch (mm)
1.26
-
Module Resolution (W x H)
240 × 135
-
Module Dimensions (W x H, mm)
302.4 × 170.1
-
Weight per Module (kg)
0.65
-
No. of Modules per Cabinet (W × H)
2 × 2
-
Cabinet Resolution (W × H)
480 × 270
-
Cabinet Dimensions (W × H × D)
604.8x340.2x72.5
-
Cabinet Surface Area (m²)
0.206
-
Weight per Cabinet (kg/cabinet)
7.4
-
Weight per Square Meter (kg/m²)
36.0
-
Physical Pixel Density (pixels/m²)
629,882
-
Flatness of Cabinet
±0.5
-
Cabinet Material
Die Casting Aluminum
-
Service Access
Front
* Min. 50mm needed between cabinet rear surface and back wall.
OPTICAL PARAMETER
-
Min. Brightness (After Calibration, cd/m²)
600
-
Color Temperature
3,000 - 10,000
-
Visual Viewing Angle (H×V)
160 × 140
-
Brightness Uniformity
97%
-
Color Uniformity
± 0.003 Cx,Cy
-
Contrast Ratio
7,000
-
Processing Depth (bit)
16
ELECTRICAL PARAMETER
-
Power Consumption (W/cabinet, Max.)
120
-
Power Consumption (W/cabinet, Avg.)
58
-
Power Consumption (W/m², Max.)
620
-
Heat Dissipation (BTU/h/Cabinet, Max.)
409
-
Heat Dissipation (BTU/h/Cabinet, Avg.)
198
-
Heat Dissipation (BTU/h/m², Max.)
2,115
-
Power Supply (V)
100 to 240
-
Frame Rate (Hz)
50 / 60
-
Refresh Rate (Hz)
3,000
OPERATION CONDITIONS
-
Lifetime (Hours to Half Brightness)
100,000
-
Operating Temperature (°C)
-10° to +40°
-
Operating Humidity
10-80%RH
-
IP rating Front / Rear
IP5X
CERTIFICATION
-
Certification
CE/FCC/cTUVus/CB
ENVIRONMENT
-
Environment
RoHS/REACH
CONTROLLER
-
Controller
LCLG006
-
