All Spec
PANEL
-
Screen Size
49"
-
Panel Technology
IPS
-
Back Light Type
Direct
-
Aspect Ratio
16 : 9
-
Native Resolution
1,920 x 1,080 (FHD)
-
Refresh Rate
60Hz
-
Brightness
500nit (Typ.)
-
Contrast Ratio
1,000:1
-
Dynamic CR
500,000 : 1
-
Color gamut
NTSC 72%
-
Viewing Angle(H x V)
178x178
-
Color Depth
10bit, 1.07Billion colors
-
Response Time
8 ms (G to G)
-
Surface Treatment(Haze)
3%
-
Life Time
60,000Hrs (Typ.) / 50,000Hrs (Min.)
-
Operation Hours (Hours/Day)
24/7
-
Portrait / Landscape
Yes / Yes
CONNECTIVITY
-
Input
HDMI (2, HDCP 1.4), DP (1, HDCP 1.3),DVI-D (1, HDCP 1.4) Audio In, RS232C IN, RJ45(LAN), IR IN, USB2.0 Type A (1)
-
Output
DP Out (Input : DP (HDCP)), Audio Out, RS232C OUT
MECHANICAL SPECIFICATION
-
Bezel Color
Black
-
Bezel Width
T/R/L/B : 2.25/1.25/2.25/1.25mm
-
Weight(Head)
16.9Kg
-
Packed Weight
29.3kg
-
Monitor Dimension(W x H x D)
1077.6 x 607.8 x 89.7mm
-
Carton Dimensions(W x H x D) (Box outer size)
1214 x 778 x 263mm
-
Handle
Yes
-
VESA™ Standard Mount Interface
600 x 400
KEY FEATURE
-
HW
Temperature Sensor
-
SW
Embedded CMS (Local Contents Scheduling), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (RS-232C Sync), Rotation (Screen Rotation), Tile Mode Setting (Max. 15x15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, 3rd Party Compatibility (Crestron Inside), Smart Energy Saving, PM mode, Wake on LAN, HDMI-CEC, SI Server Setting, W/B Setting by Grey scale, Scan Inversion
ENVIRONMENT CONDITIONS
-
Operation Temperature
0 °C to 40 °C
-
Operation Humidity
10 % to 80 %
POWER
-
Power Supply
AC 100-240V~, 50/60Hz
-
Power Type
Built-In Power
POWER CONSUMPTION
-
Typ.
100W
-
Max.
120W
-
BTU (British Thermal Unit)
341 BTU/Hr(Typ.), 409 BTU/Hr(Max)
-
Smart Enegy Saving
60W
-
DPM
0.5W
-
Power off
0.5W
CERTIFICATION
-
Safety
CB / NRTL
-
EMC
FCC Class "A" / CE / KC
-
ErP / Energy Star
Yes / Energy Star 8.0(US Only)
SOFTWARE COMPATIBILITY
-
SuperSign CMS
Yes
-
SuperSign Control / Control+
Yes / Yes
-
SuperSign WB
Yes
-
SuperSign Media Editor
Yes
-
Connected Care
Yes
LANGUAGE
-
OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic
ACCESSORY
-
Basic
Remote Controller(include battery 2ea), Power Cord, RS232C cable, DP cable, IR Receiver, Guide Bracket, Screws, Manual
-
Optional
Wall Mount ( Landscape : WM-L640V, Portrait : WM-P640V)
-
