55" LG Video Wall LV77A SERIES

Specs

Support

Resource

55" LG Video Wall LV77A SERIES

Share this content.

You can share the items you like with your friends

55LV77A

55" LG Video Wall LV77A SERIES

Print

All Spec

PANEL

  • Screen Size

    55" (139.7cm)

  • Aspect Ratio

    16:9

  • Native Resolution

    1920 x 1080 (FHD)

  • Brightness

    700 cd/m²

  • Contrast Ratio

    1,400:1

  • Viewing Angle (HxV)

    178° x 178°

  • Supported Colours

    Black

  • Response Time

    12ms (G to G)

  • Dynamic CR

    500,000:1

  • Panel Technology

    IPS

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Off

    0.5W

  • Power Type

    Built-In Power

  • DPM

    0.5W (RGB), 0.7W (HDMI)

  • Typical / Smart Energy Saving

    230W/120W

SPECIAL FEATURES

  • Additional

    Time, Information, Temprature Sensor, Languages,Position/Size, DPM Select, File Play with USB,PIP/PBP, Tile mode, Source Selection, Auto config/Phase, ISM Method, Input Label, Smart Energy Saving, Auto power/Source Memory, Brightness/Contrast/Backlight

ENVIRONMENT CONDITIONS

  • Operation Humidity

    10% to 80%

  • Operation Temperature

    0°C to 40°C

PHYSICAL SPECIFICATION

  • Bezel Width

    2.25mm (L/T)/1.25mm (R/B)

  • Weight (head)

    23.2kg

  • Carton Dimensions (W x H x D)

    1353mm x 850mm x 255mm

  • Monitor Dimension(W x H x D cm)

    1213.4mm x 684.2mm x 88.5mm

  • Packed Weight

    30.5kg

  • VESA™ Standard Mount Interface

    600mm × 400mm

CONNECTIVITY INPUT

  • Digital

    DVI-D (1), HDMI (1), Display Port (1) with HDCP for all input

  • Analog

    RGB (1), Shared Component (1), AV (1)

  • Audio

    PC Audio In (1)

  • External Control

    RS232C (1), RJ45 (1), IR (1)

  • USB

    Yes (1)

CONNECTIVITY OUTPUT

  • Digital

    Display Port (1)

  • Audio

    Audio Out (1)

  • External Control

    RS232C (1)

STANDARD(CERTIFICATION)

  • Safety

    UL/cUL/CB scheme/TUV/KC

  • EMC

    FCC Class "B"/CE/KCC/C-Tick

  • ErP / Energy Star

    Yes/Yes (Energy Star 6.0)

MEDIA PLAYER COMPATIBILITY

  • Slot PC Compatible (optional)

    No

  • External Media Player Attachable

    Yes

ACCESSORY

  • Included

    RC, DP Cable, Manual, Tiling Guide, Power Cable, IR Receiver, RS-232C Cable, Screw

  • Optional

    600 x 400 (AP-WX60), WM-L640V (Landscape), WM-P640V (Portrait)

To access more technical documentation and resources, please visit the LG B2B partner portal.
