Air Flow Rate - Cooling, Max/H/M/L
10.5/9/6.6/4.2 m³/min371/318/233/148 CFM
Fan Motor Speed - Cooling, Max/H/HM/M/ML/L/SL
1350/1150/1020/900/770/650/480 rpm
Sound Pressure Level - Cooling, Max/H/M/L/SL
-/39/33/27/21 dB(A)
Dimensions (W × H × D) - Net
837 x 308 x 189 mm
Dimensions (W × H × D) - Shipping
897 x 390 x 254 mm
Weight - Net
8.7kg
Weight - Shipping
10.5kg
Disconnect Switch
15 A
Exterior Color Code
Munsell 7.5BG 10/2 (RAL 9016)
Operation Range - Cooling
16 ~ 32 °C DB61 ~ 90 °F DB 10 ~ 23 °C WB50 ~ 73.4 °F WB
Air Flow Rate - Max
28.0 m³/min989 CFM
Sound Pressure Level - Cooling, Rated
50 dB(A)
Dimensions (W × H × D) - Net
717 x 495 x 230 mm
Dimensions (W × H × D) - Shipping
839 x 532 x 324 mm
Weight - Net
21.7kg
Weight - Shipping
23.5kg
Max. Fuse Size
15 A
Exterior Color Code
Munsell 9.54Y 8.34/1.31 (RAL 9001)
Operation Range - Cooling
18 ~ 48 °C DB
Cooling (Min ~ Rated ~ Max)
770 W
EER
3.50 W/W 11.95 (Btu/h)/W12.61 (kJ/h)/W
Evaporator - Material, Tube / Fin
Cu/Al
Evaporator - (ø x Row x Column x FPI x L) x Qty.
(ø7 x 2 x 15 x 21 x 616.8) x 1
Evaporator - Corrosion Protection
PCM
Evaporator - Fin Type
Slit
Condenser - Material, Tube / Fin
Cu/Al
Condenser - (ø x Row x Column x FPI x L) x Qty.
(ø7 x 1 x 22 x 21 x 667.5) x 1
Condenser - Corrosion Protection
Gold
Condenser - Fin Type
Louver
Type
Twin Rotary
Model
DST066MAA
Motor Type
BLDC
Oil Type / Maker
PVE (FW68D) / IDEMITSU
Oil Charge
220cc
Manufacturer / Country of Origin
LG Electronics / China
Type
R32
Pre Charge
500g
Additional Charge
15g/m
Control
Capillary
Global Warning Potential
675
t-CO₂ eq
0.338
Cooling (Min ~ Rated ~ Max)
4.40 A
Power Supply
1, 230, 60 (Ø, V, Hz)
Available Voltage Range
187 ~ 276 V
Power Factor - Cooling
93%
Moisture Removal
1.25 l/h2.64 pts/h
Circuit Breaker
15 A
Power Supply Cable
3 × 1 No. × mm²
Power Supply to Unit
Indoor
Power and Communication Cable
4 × 1 No. × mm²
Cooling (Min ~ Rated ~ Max)
2.70 kW 9,200 Btu/h 9,706 kJ/h
Capacity
1.0HP
Size - Liquid
ø 6.35 mm
Size - Gas
ø 9.52 mm
Connections Method - Indoor/Outdoor
Flared/Flared
Drain Hose Size - O.D, I.D
21.5, 16.0 mm
Max Piping Length Capacity
98.7%
Piping Length - Min/Standard/Max
3/7.5/20 m
Piping Length - No Charge
12.5 m
Max. Elevation Difference
15 m
Piping Connection Heat Insulation
Both liquid and gas pipes
Type
Cross Flow Fan
Motor Output
30W
Type
Propeller Fan
Motor Type
AC
Motor Output
25W
Motor Insulation
Class B
Motor Enclosure / Ingress Protection
TEAO/IP44
Indoor / Outdoor
SJ / UA3
