*The TÜV Rheinland test conducted in compliance with ISO 20743:2007 verified that
the UVnano LED removes 99.99 percent of Staphylococcus aureus, Staphylococcus epidermidis, and Klebsiella pneumoniae from the air conditioner blower fan after being exposed to UV LED lights, located underneath the fan, for 4 hours. The models tested include the S3NM12JL1GA (SJ), S3NM09AA1MA (SA) and S3NM24K21GA (SK). Test results do not mean that the air conditioner releases air that is 99.99% bacteria-free. The efficacy in bacteria removal may differ in actual conditions.
*KTR test conducted in compliance with ISO 20743:2007 verified that
the UVnano LED removes 99.99 percent of Staphylococcus aureus, Staphylococcus epidermidis, and Klebsiella pneumoniae from the air conditioner blower fan after being exposed to UV LED lights, located underneath the fan, for 4 hours. The models tested include the S3NM12JL1GA (SJ), S3NM09AA1MA (SA) and S3NM24K21GA (SK). Test results do not mean that the air conditioner releases air that is 99.99% bacteria-free. The efficacy in bacteria removal may differ in actual conditions.
*The TÜV Rheinland test verified that the Plasmaster™Ionizer+ removed up to 99 percent of adhering bacteria (Staphylococcus aureus, Escherichia coli and Pseudomonas aeruginosa) in the test room of 30m.3 The model tested was SW09BAJWAN.
*Intertek verified that tobacco adhesive odor intensity (Toluene, Ammonia, Acetic acid) is reduced from 3.6 to under 1.5 after 60 minutes of operation in testing area of 8m3. The model tested was R24AWN. The efficiency in bacteria removal may differ in actual conditions.
LG inverter air conditioners(US-Q242K*) cools up to 40% more faster than LG non-inverter air conditioners(TS-H2465DAO). *Initial Temperature(Outdoor 35℃, Indoor 33℃), Setting Temperature(26℃).
LG inverter air conditioners(US-Q242K*) saves up to 70% more energy than LG non-inverter air conditioners(TS-H2465DAO). *Initial Temperature(Outdoor 35℃, Indoor 33℃), Setting Temperature(26℃), Testing Time (8 Hours).
*According to LG internal test, LG DUAL Inverter air conditioner is less than 19dBA. (Model - V10API)
*One (1) year warranty on parts and labor.
**Ten (10) years warranty for inverter compressor part only, applicable from Y2015 models. Labor is chargeable to customer after one (1) year from purchase.
With a 10-year warranty on the compressor, it will keep performing at its best for longer.
*Google and Google Home are trademarks of Google LLC. *Amazon, Alexa, Echo and all related logos and motion marks are trademarks of Amazon.com, Inc or its affiliates. *LG SmartThinQ is now renamed as LG ThinQ. *Smart features and voice assistant product may vary by country and model. Check with your local retailer or LG for service availability. *Voice-enabled smart speaker device is not included.
Prevent environmental pollution with R32 refrigerant's improved energy efficiency.
Cooling (Min ~ Rated ~ Max)
1.43 ~ 3.30 ~ 3.58 kW
4,882 ~ 11,260 ~ 12,199 Btu/h
5,150 ~ 11,879 ~ 12,870 Btu/h
Capacity
1.5HP
Cooling (Min ~ Rated ~ Max)
305 ~ 840 ~ 1,050 W
Cooling (Min ~ Rated ~ Max)
1.60 ~ 4.10 ~ 5.00 A
EER
3.93 W/W
13.40 (Btu/h)/W
14.14 (kJ/h)/W
Power Supply
1, 230, 60 (Ø, V, Hz)
Available Voltage Range
187 ~ 276 V
Power Factor - Cooling
97%
Moisture Removal
1.25 l/h
Air Flow Rate - Cooling, Max/H/M/L
13 / 10 / 6.6 / 4.2 m³/min
Sound Pressure Level - Cooling, Max/H/M/L/SL
- / 41 / 35 / 27 / 21 dB(A)
Dimensions (W × H × D) - Net
837 x 308 x 189 mm
Dimensions (W × H × D) - Shipping
897 x 390 x 254 mm
Weight - Net
8.7kg
Weight - Shipping
10.5kg
Exterior Color Code
Munsell 7.5BG 10/2 (RAL 9016)
Air Flow Rate - Max
28.0 m³/min
Fan Motor Speed - Cooling, Min ~ Max
230 ~ 900 rpm
Sound Pressure Level - Cooling, Rated
50 dB(A)
Dimensions (W × H × D) - Net
720 x 500 x 230 mm
Dimensions (W × H × D) - Shipping
839 x 532 x 324 mm
Weight - Net
23.9kg
Weight - Shipping
25.9kg
Max. Fuse Size
20A
Exterior Color Code
Munsell 9.54Y 8.34/1.31 (RAL 9001)
Operation Range - Cooling
18 ~ 48 °C DB
Circuit Breaker
15A
Power Supply Cable
3 x 1 No. x mm²
Power Supply to Unit
Indoor
Power and Communication Cable
4 x 1 No. x mm²
Size - Liquid
ø 6.35 mm
Size - Gas
ø 9.52 mm
Connections Method - Indoor/Outdoor
Flared/Flared
Drain Hose Size - O.D, I.D
21.5, 16.0 mm
Piping Length - Min/Standard/Max
3/7.5/20 m
Piping Length - No Change
12.5 m
Max. Elevation Difference
15m
Piping Connection Heat Insulation
Both liquid and gas pipes
Type
R32
Pre Charge
680g
Additional Charge
10g/m
Control
Capillary
Global Warning Potential
675
t-CO₂ eq
0.459
Type
Twin Rotary
Model
DST066MAA
Motor Type
BLDC
Oil Type / Maker
PVE (FW68D) / IDEMITSU
Oil Charge
280cc
Manufacturer / Country of Origin
LG Electronics / China
Type
Cross Flow Fan
Motor Output
30W
Type
Propeller Fan
Motor Type
BLDC
Motor Output
43W
Motor Insulation
Class E
Motor Enclosure / Ingress Protection
TEAO/IPX4
Evaporator - Material, Tube / Fin
Cu/Al
Evaporator - (ø x Row x Column x FPI x L) x Qty.
(ø7 x 2 x 15 x 21 x 616.8) x 1
Evaporator - Corrosion Protection
PCM
Evaporator - Fin Type
Slit
Condenser - Material, Tube / Fin
Cu/Al
Condenser - (ø x Row x Column x FPI x L) x Qty.
(ø7 x 2 x 22 x 18 x 667) x 1
Condenser - Corrosion Protection
Gold
Condenser - Fin Type
Louver
