Cooling (Min ~ Rated ~ Max)
1.43 ~ 3.30 ~ 3.58 kW
4,882 ~ 11,260 ~ 12,199 Btu/h
5,150 ~ 11,879 ~ 12,870 Btu/h
Capacity
1.5HP
Cooling (Min ~ Rated ~ Max)
305 ~ 840 ~ 1,050 W
Cooling (Min ~ Rated ~ Max)
1.60 ~ 4.10 ~ 5.00 A
EER
3.93 W/W
13.40 (Btu/h)/W
14.14 (kJ/h)/W
Power Supply
1, 230, 60 (Ø, V, Hz)
Available Voltage Range
187 ~ 276 V
Power Factor - Cooling
97%
Moisture Removal
1.25 l/h
Air Flow Rate - Cooling, Max/H/M/L
13 / 10 / 6.6 / 4.2 m³/min
Sound Pressure Level - Cooling, Max/H/M/L/SL
- / 41 / 35 / 27 / 21 dB(A)
Dimensions (W × H × D) - Net
837 x 308 x 189 mm
Dimensions (W × H × D) - Shipping
897 x 390 x 254 mm
Weight - Net
8.7kg
Weight - Shipping
10.5kg
Exterior Color Code
Munsell 7.5BG 10/2 (RAL 9016)
Air Flow Rate - Max
28.0 m³/min
Fan Motor Speed - Cooling, Min ~ Max
230 ~ 900 rpm
Sound Pressure Level - Cooling, Rated
50 dB(A)
Dimensions (W × H × D) - Net
720 x 500 x 230 mm
Dimensions (W × H × D) - Shipping
839 x 532 x 324 mm
Weight - Net
23.9kg
Weight - Shipping
25.9kg
Max. Fuse Size
20A
Exterior Color Code
Munsell 9.54Y 8.34/1.31 (RAL 9001)
Operation Range - Cooling
18 ~ 48 °C DB
Circuit Breaker
15A
Power Supply Cable
3 x 1 No. x mm²
Power Supply to Unit
Indoor
Power and Communication Cable
4 x 1 No. x mm²
Size - Liquid
ø 6.35 mm
Size - Gas
ø 9.52 mm
Connections Method - Indoor/Outdoor
Flared/Flared
Drain Hose Size - O.D, I.D
21.5, 16.0 mm
Piping Length - Min/Standard/Max
3/7.5/20 m
Piping Length - No Change
12.5 m
Max. Elevation Difference
15m
Piping Connection Heat Insulation
Both liquid and gas pipes
Type
R32
Pre Charge
680g
Additional Charge
10g/m
Control
Capillary
Global Warning Potential
675
t-CO₂ eq
0.459
Type
Twin Rotary
Model
DST066MAA
Motor Type
BLDC
Oil Type / Maker
PVE (FW68D) / IDEMITSU
Oil Charge
280cc
Manufacturer / Country of Origin
LG Electronics / China
Type
Cross Flow Fan
Motor Output
30W
Type
Propeller Fan
Motor Type
BLDC
Motor Output
43W
Motor Insulation
Class E
Motor Enclosure / Ingress Protection
TEAO/IPX4
Evaporator - Material, Tube / Fin
Cu/Al
Evaporator - (ø x Row x Column x FPI x L) x Qty.
(ø7 x 2 x 15 x 21 x 616.8) x 1
Evaporator - Corrosion Protection
PCM
Evaporator - Fin Type
Slit
Condenser - Material, Tube / Fin
Cu/Al
Condenser - (ø x Row x Column x FPI x L) x Qty.
(ø7 x 2 x 22 x 18 x 667) x 1
Condenser - Corrosion Protection
Gold
Condenser - Fin Type
Louver
