Class is being conducted in the classroom, and the class material screen which is displayed on the classroom wall's LG CreateBoard is being shared on the students' tablets.
* All images in this page are for illustrative purposes only.
Students are solving problems using various ruler models on the LG CreateBoard menu.
"In the classroom, several students are simultaneously writing on the LG CreateBoard screen. "
* A max of 32 points are recognized in the Android environment, and a max of 40 points are detected in the Windows environment..
* Up to 10 points can be recognized in the writing app.
Materials used to conduct class can be shared through the LG CreateBoard's import and export function after class.
The LG CreateBoard can easily share screens with multiple devices in real time via app and website.
* LG CreateBoard also supports app-less sharing for PC (via website) and mobile devices within the same network.
* For a more stable connection, we recommend the installation of a dedicated app (LG CreateBoard Share).
An IT manager is managing/controlling the status of the LG CreateBoard through LG ConnectedCare DMS.
* 'LG ConnectedCare DMS' needs to be purchased separately.
* The availability of the 'LG ConnectedCare DMS' service differs by region, so please contact the LG sales representative in your region for more details.
* LG ConnectedCare DMS supports the TR3DJ/TR3PJ/TR3DK Series as of now(plus more to come) under a cloud environment.
Frequently used controls such as the power on/off, scheduling, brightness, and screen lock functions can be applied using a remote control.
Messages and a range of other content can be sent from the main system to individual classroom devices connected to LG ConnectedCare DMS. In case of urgent occasions such as a fire or a natural disaster, alert messages can be distributed manually across the system, which help teachers and students promptly take safety action.
the_user_can_set_a_threshold_for_receiving_an_warning/error signal for eight categories_ display temperature, CPU usage, etc. The current status of the issue is easily indicated in categories, enabling for quick real-time responses. Issues can be managed remotely with an LG ConnectedCare DMS solution.
Users can set thresholds in eight categories including display temperature, memory usage, or signal, and can receive warning or error notifications based on their threshold settings.
An engineer can check the status in real-time and diagnose problems remotely. Also, the current status of issues can be categorized, allowing for easy viewing and quick responses.
Remote issue management can be carried out by the LG ConnectedCare DMS solution. This makes management safer and more efficient, facilitating the stable operation of the classroom.
The LG CreateBoard can wirelessly connect to devices such as keyboards, mice, and speakers via Bluetooth.
The LG CreateBoard easily transmits data via USB-C connectivity and can charge up to 65W.
* USB Type-C cables are sold separately.
Teachers can lock the screen using the Screen Lock function, and unlock it by entering a password. Users can set the Screen Lock in the Settings menu to protect the device from unidentified users.
LG CreateBoard supports Secure Mode that disables the LG CreateBoard Share function to prevent unauthorized content from being shown on various devices.
USB Lock Mode is a security measure that helps prevent data from being copied to unauthorized devices, which is essential when being used in spaces where security is critical.
Users can set LG CreateBoard to delete files regularly for enhanced security.
Screen Size (Inch)
86"
Panel Technology
IPS
Back Light Type
Direct
Aspect Ratio
16:9
Native Resolution
3840x2160 (UHD)
Refresh Rate
60 Hz
Brightness
440nit(wo Glass, max), 390nit (wo Glass, typ)
400nit(w Glass, typ), 350nit (w Glass, typ)
Contrast Ratio
1200:1
Dynamic CR
5000:1
Color Gamut
NTSC 68%
Viewing Angle (H x V)
178°(H/V)
Color Depth (Number of Colors)
1.07B(10bit)
Response Time
8 ms
Surface Treatment (Haze)
Haze 28%
Life time
≥30000 Hours
Operation Hours (Hours/Day)
16/7
Portait / Landscape
No / Yes
Bezel Color
Black
Bezel Width
T/R/L/B : 15/15/15/44mm
Weight (Head)
58.6Kg
Packed Weight
75.9Kg
Monitor Dimensions (W x H x D)
1957×1160×100mm
Handle
Yes
VESA Standard Mount Interface
800×600mm
Operation Temperature
0 ~ 40 °C
Operation Humidity
10 ~ 90 % RH
Power Supply
100-240V~ 50/60Hz 4.0A
Power Type
Built-in Power
Typ.
385W
Max.
580W
BTU (British Thermal Unit)
1314 BTU/Hr(Typ.), 1979 BTU/Hr(Max)
DPM
≤0.5W
Power off
≤0.5W
Speaker (Built-in)
Yes (15W x 2)
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ERP / Energy Star
Yes / Yes
OPS Power Built-in
Yes
OPS Type compatible
Yes (Slot)
OSD
English, Denmark, Finnish, German, Korean, Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Spanish, Swedish, Hungarian, Thai
Basic
Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional
Wall Mount(WM-L000S), Floor Stand(ST-000F)
