Smart Inverter

Specs

Reviews

Support

Smart Inverter

Smart Inverter

BS-Q096J3A3
()
  • LG Smart Inverter, BS-Q096J3A3
  • LG Smart Inverter, BS-Q096J3A3
  • LG Smart Inverter, BS-Q096J3A3
  • LG Smart Inverter, BS-Q096J3A3
  • LG Smart Inverter, BS-Q096J3A3
  • LG Smart Inverter, BS-Q096J3A3
  • LG Smart Inverter, BS-Q096J3A3
LG Smart Inverter, BS-Q096J3A3
LG Smart Inverter, BS-Q096J3A3
LG Smart Inverter, BS-Q096J3A3
LG Smart Inverter, BS-Q096J3A3
LG Smart Inverter, BS-Q096J3A3
LG Smart Inverter, BS-Q096J3A3
LG Smart Inverter, BS-Q096J3A3

Key Features

  • Inverter Compressor
  • Active Energy Control
  • Comfort Air

Summary

Print

Dimensions

All specs

PERFORMANCE

  • Cooling Capacity (W)

    2,696

  • Cooling Capacity ( Btu/h)

    9,200

  • Capacity Rate (Min)

    2,200 Btu/h

  • Capacity Rate (Max)

    11,900 Btu/h

  • Power Input - Cooling/Heating

    720 W

  • Power Input - Cooling/Heating (Max)

    1050 W

  • Running Current - Cooling/Heating

    4.0 A

  • Running Current - Cooling/Heating (Max)

    6.0 A

  • EER (W/W)

    3.74

  • EER ( Btu/W.h)

    12.78

  • Power Supply

    1 / 220~240 / 50 Ø / V / Hz

  • Air Flow Rate - Indoor (Max)

    11.0 ㎥/min

  • Air Flow Rate - Outdoor (Max)

    28 ㎥/min

  • Moisture Removal

    0.4 l/h

  • Sound Level - Indoor (H/M/L/SL)

    36/30/24/18 dB(A)+3

  • Sound Level - Outdoor (Max)

    47 dB(A)+3

  • Standard Pipe length

    7.5 m

  • Fan Type (Indoor)

    Cross Flow Fan

  • Fan Type (Outdoor)

    Fan,Propeller

  • Refrigerent (Kg)

    R410A (0.58)

  • Piping Connections (Liquid Side)

    6.35 mm

  • Piping Connections (Gas Side)

    9.52 mm

  • Dimensions - Indoor (W*H*D) (mm)

    837*302*189

  • Dimensions - Outdoor (W*H*D) (mm)

    720*500*270

  • Net Weight - Indoor

    8.5 Kg

  • Net Weight - Outdoor

    20.5 Kg

TICKS

  • Number of Ticks

    2

APPEARANCE - INDOOR

  • Tool Code

    SJ

  • Remote

    2 Way + Watt Option

  • Remote Controller Type

    Wireless LCD

  • Grille Front Look

    Sirius E (White)

  • Display

    88 Display

APPEARANCE - OUTDOOR

  • Tool Code

    UA3

  • Panel Type

    Steel

  • Condenser Type

    CU

FEATURE & FUNCTION

  • Anti bacteria air filter (Stallion Prefilter) (in Front Grille)

    Yes (Top Filter)

  • Micro Dust Filter (single)

    Yes

  • * Vane Horizontal

    Normal

  • Temperature Control

    Thermistor

  • Auto Clean

    Yes

  • Natural Wind

    Yes

  • Fan Speed (SH/H/MH/M/ML/L/SL)

    7

  • Airflow Direction Control (up & Down)

    Auto

  • Airflow Direction Control (left & right)

    Manual

  • Setting Temperature Range - Cooling (°C)

    16-30

  • Temperature Increment

    1°C

  • Auto Operation (Micom Control)

    Yes

  • Self Diagnosis

    Yes

  • Timer

    24hr On/Off

  • Sleep Operation

    Yes

  • Restart Delay (minute)

    3

  • Display Light (On/Off)

    Yes

  • Jet Cool

    Yes

  • Fresh Dry

    Yes

  • Indirect Air

    Yes

  • Active Energy Control

    Yes

  • Dry Contact

    Yes

  • Power Supply

    Indoor

  • 10Y Compressor Warranty

    No
