Pitch Name
3 in 1 SMD
Pixel Pitch (mm)
1.563
Module Resolution (W x H)
192 × 108
Module Dimensions (W x H, mm)
300 × 168.75
Weight per Module (kg)
0.60
No. of Modules per Cabinet (W × H)
2 × 2
Cabinet Resolution (W × H)
384 × 216
Cabinet Dimensions (W × H × D)
600 × 337.5 × 33.8
Cabinet Surface Area (m²)
0.203
Weight per Cabinet (kg/cabinet)
6.0
Weight per Square Meter (kg/m²)
29.6
Physical Pixel Density (pixels/m²)
409,600
Flatness of Cabinet
± 0.1 mm
Cabinet Material
Die Casting Aluminum Alloy
Service Access
Front
Max Brightness (After Calibration)
800
Color Temperature
3,200-9,300 (K)
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
97%
Color Uniformity
± 0.003 Cx,Cy
Contrast Ratio
5,000
Processing Depth (bit)
14
Power Consumption (W/cabinet, Max.)
150
Power Consumption (W/cabinet, Avg.)
50
Power Consumption (W/m², Max.)
740
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature (°C)
-10 °C to +45 °C
Operating Humidity
0 - 80 % RH
IP rating Front / Rear
IP30 / IP30
Input Interface
HDMI / DP / OPS / USB
Input Resolution
3,840 x 2,160 @60Hz
Output Signal
Gigabit Ethernet (16 ea)
Output Fiber Optical
No
Control RJ45
Yes
Control USB
No
Electrical Power Consumption (W)
50
Electrical Power Supply (V)
AC 100-240 V
Mechanical Size (mm)
443 (W) × 307.5 (D) × 63 (H) → EIA Standard Rack (2U)
Mechanical Weight (kg)
4.9
Feature Signal Redundancy
Yes
Feature HDR10
Yes
Input Interface
HDMI / DVI
Input Resolution
1,920 x 1,200 @60Hz
Output Signal
Gigabit Ethernet (4 ea)
Output Fiber Optical
No
Control RJ45
No
Control USB
Yes
Electrical Power Consumption (W)
16
Electrical Power Supply (V)
AC 100-240 V
Mechanical Size (mm)
482.6 (W) × 250 (D) × 44.45 (H) → EIA Standard Rack (1U)
Mechanical Weight (kg)
2.9
Feature Signal Redundancy
Yes
Feature HDR10
No
Input Interface
HDMI / DVI / DP
Input Resolution
3,840 x 2,160 @60Hz
Output Signal
Gigabit Ethernet (16 ea)
Output Fiber Optical
4 ea
Control RJ45
Yes
Control USB
Yes
Electrical Power Consumption (W)
30
Electrical Power Supply (V)
AC 100-240 V
Mechanical Size (mm)
482.6 (W) × 250 (D) × 96 (H) → EIA Standard Rack (3U)
Mechanical Weight (kg)
4.6
Feature Signal Redundancy
Yes
Feature HDR10
Yes
