49" 700 nits FHD Narrow Bezel Video Wall
All Spec
PANEL
-
Screen Size
49"
-
Panel Technology
IPS
-
Aspect Ratio
16 : 9
-
Native Resolution
1,920 x 1,080 (FHD)
-
Brightness (Typ., cd/m²)
700
-
Contrast Ratio
1,300:1
-
Dynamic CR
500,000 : 1 (The luminosity ratio of Full Black/Full White color on video input condition.)
-
Viewing Angle (H x V)
178 x 178
-
Response Time
8 ms (G to G)
-
Surface Treatment
3%
-
Life Time (Typ.)
60,000 Hrs
-
Operation Hours
24 Hrs
-
Orientation
Landscape & Portrait
CONNECTIVITY
-
Input
HDMI, DP, DVI-D, RGB, Audio, USB
-
Output
DP, Audio
-
External Control
RS232C In/out, RJ45(LAN) In, IR In
MECHANICAL SPECIFICATION
-
Bezel Color
Black
-
Bezel Width
2.25 mm (T/L), 1.25 mm (B/R)
-
Monitor Dimension (W × H × D)
1,077.6 x 607.8 x 89.7 mm
-
Weight (Head)
17.8 kg
-
Carton Dimensions (W × H × D)
1,214 x 778 x 263 mm
-
Packed Weight
22.8 kg
-
Handle
Yes
-
VESA™ Standard Mount Interface
600 x 400 mm
ENVIRONMENT CONDITIONS
-
Operation Temperature
0°C to 40°C
-
Operation Humidity
10 % to 80 %
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Type
Built-In Power
POWER CONSUMPTION
-
Typ./Max
140 W / 165 W
-
Smart Energy Saving
75 W
CERTIFICATION
-
Safety
CB / NRTL
-
EMC
FCC Class "A" / CE / KC
-
ErP / Energy Star
Yes(EU Only) / Yes (Energy Star 8.0)
MEDIA PLAYER COMPATIBILITY
-
OPS type compatible
No
SOFTWARE COMPATIBILITY
-
Content Management Software
SuperSign CMS
-
Control and Monitoring Software
SuperSign Control/Control+
ACCESSORY
-
Basic
Remote Controller, Power Cord, RS232C Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual
-
Optional
Wall Mount (Landscape: WM-L640V, Portrait: WM-P640V)
