98" 500 nits 120 Hz UHD Signage

98" 500 nits 120 Hz UHD Signage

98UH5F-B

98" 500 nits 120 Hz UHD Signage

All Spec

PANEL

  • Screen Size

    98"

  • Panel Technology

    IPS

  • Native Resolution

    3,840 x 2,160 (UHD)

  • Refresh Rate

    120Hz

  • Brightness(Typ.,cd/m²)

    500

  • Contrast Ratio

    1,300:1

  • Viewing Angle (H x V)

    178 x 178

  • Response Time

    8ms (G to G)

  • Surface Treatment (Haze)

    Haze 1%

  • Life Time (Typ.)

    50,000 Hrs

  • Operation Hours

    24Hrs

  • Orientation

    Portrait & Landscape

CONNECTIVITY

  • Input

    HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)

  • Output

    DP, Audio (Off/Fixed/Variable)

  • External Control

    RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In

MECHANICAL SPECIFICATION

  • Bezel Color

    Black

  • Bezel Width

    14.9 mm (Even) * Off-Bezel

  • Monitor Dimension (W × H × D)

    2,191.8 x 1,246.8 x 83.8 mm (without Handle and Logo)

  • Weight (Head)

    81.1 kg

  • Carton Dimensions (W × H × D)

    2,354 x 1,386 x 420 mm

  • Packed Weight

    119 kg

  • Handle

    Yes

  • VESA™ Standard Mount Interface

    800 x 400 mm

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0°C to 40°C

  • Operation Humidity

    10% to 80%

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Type

    Built-In Power

POWER CONSUMPTION

  • Typ. / Max.

    420 W / 560 W

  • Smart Energy Saving

    294 W

CERTIFICATION

  • Safety

    CB / NRTL

  • EMC

    FCC Class "A" / CE / KC

  • ErP / Energy Star

    Yes (EU Only) / N/A

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible

    No

SOFTWARE COMPATIBILITY

  • Content Management Software

    SuperSign CMS

  • Control and Monitoring Software

    SuperSign Control/Control+

ACCESSORY

  • Basic

    Remote Controller, Power Cord, QSG, IR/Light Sensor Receiver, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender, EYE-BOLT

  • Optional

    No

COMPLIANCE INFORMATION

The safety information for accessories is included with the safety information for the product and is not provided separately.

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
