All Spec
SEASONAL EFFICIENCY DATA
-
Seasonal space heating eff. class (35℃ / 55℃)
-
A+++/A++
-
Seasonal space heating efficiency (ηS) (35℃ / 55℃)
-
175 / 125
-
SCOP (35℃ / 55℃)
-
4.46 / 3.20
NOMINAL CAPACITY AND COP (A+7/W+35)
-
Heating capacity (kW)
-
5.50
-
COP
-
4.70
NOMINAL CAPACITY AND COP (A+2/W+35)
-
Heating capacity (kW)
-
4.40
-
COP
-
3.60
NOMINAL CAPACITY AND COP (A+7/W+55)
-
Heating capacity (kW)
-
5.50
-
COP
-
2.70
NOMINAL CAPACITY AND EER (A+35/W+18)
-
Cooling capacity (kW)
-
5.50
-
EER
-
4.70
NOMINAL CAPACITY AND EER (A+35/W+7)
-
Cooling capacity (kW)
-
5.50
-
EER
-
3.30
OPERATION RANGE (OUTDOOR AIR TEMPERATURE)
-
Heating & DHW (Min. ~ Max.) (℃)
-
-25 ~ 35
-
Cooling (Min. ~ Max.) (℃)
-
5 ~ 48
OPERATION RANGE (LEAVING WATER TEMPERATURE)
-
Heating (Min. ~ Max.) (℃)
-
15 ~ 65
-
Cooling (Min. ~ Max.) (℃)
-
5 ~ 27
-
DHW (Min. ~ Max.) (℃)
-
15 ~ 80
REFRIGERANT
-
Type
-
R32
-
GWP
-
675
-
Precharged amount (g)
-
1,400
PIPING CONNECTIONS (WATER)
-
Inlet diameter (inch)
-
Male PT 1"
-
Outlet diameter (inch)
-
Male PT 1"
SOUND POWER LEVEL
-
Rated / low noise mode (dB(A))
-
57 / 54
SOUND PRESSURE LEVEL AT 1M (CONVERT USING SWL)
-
Rated / low noise mode (dB(A))
-
49 / 46
SOUND PRESSURE LEVEL AT 5M (CONVERT USING SWL)
-
Rated / low noise mode (dB(A))
-
35 / 32
DIMENSION
-
W × H × D (mm)
-
1,239 × 834 × 330
WEIGHT
-
Empty (kg)
-
89.5
EXTERIOR
-
Color
-
Warm gray
-
RAL code
-
RAL 7044
POWER SUPPLY
-
Voltage, phase, frequency (V, Ø, Hz)
-
220-240, 1, 50
COMPLIANCE INFORMATION
