R32 Split 5/7/9 kW Hydro Box, 1Ø, 9kW
Key Features
Refrigerant pipe robust to cold ensures no potential risk of pipe freezing even during prolonged blackouts.
Wide operation range ensures remarkable heating performance even in an extremely cold weather.
Noise reduction technology provides quieter and more comfortable experience, increasing installation flexibility in urban areas.
Indoor unit (W × H × D) (mm)
490 × 850 × 315
Outdoor unit (W × H × D) (mm)
950 × 834 × 330
Indoor unit (Color / RAL code)
Noble white / RAL 9016
Outdoor unit (Color / RAL code)
Warm gray / RAL 7044
COP
3.50
Heating capacity (kW)
5.40
COP
4.65
Heating capacity (kW)
9.00
COP
2.70
Heating capacity (kW)
5.50
Cooling capacity (kW)
9.00
EER
4.20
Cooling capacity (kW)
9.00
EER
2.60
Cooling (Min. ~ Max.) (℃)
5 ~ 27
DHW (Min. ~ Max.) (℃)
15 ~ 80
Heating (Min. ~ Max.) (℃)
15 ~ 65
Cooling (Min. ~ Max.) (℃)
5 ~ 48
Heating & DHW (Min. ~ Max.) (℃)
-25 ~ 35
Gas (mm (inch))
Ø 15.88 (5/8)
Length standard / Max. (m)
5 / 50
Level difference Max. (m)
30
Liquid (mm (inch))
Ø 9.52 (3/8)
Mass of additional ref. charge (g/m)
40
Max. length without additional charge (m)
10
Inlet diameter for space heating (inch)
Male PT 1"
Outlet diameter for space heating (inch)
Male PT 1"
Voltage, phase, frequency (V, Ø, Hz)
220-240, 1, 50
GWP
675
Precharged amount (g)
1,500
Type
R32
Seasonal space heating efficiency (ηS) (35℃ / 55℃)
183 / 126
SCOP (35℃ / 55℃)
4.65 / 3.23
Seasonal space heating eff. class (35℃ / 55℃)
A+++/A++
Rated (dB(A))
44
Rated / low noise mode (dB(A))
60 / 58
Rated (dB(A))
36
Rated / low noise mode (dB(A))
38 / 36
Indoor unit (Empty) (kg)
38.1
Outdoor unit (Empty) (kg)
60.0
