All Spec
POWER SUPPLY
-
Voltage, phase, frequency for indoor unit (V, Ø, Hz)
-
220 ~ 240, 1, 50
-
Voltage, phase, frequency for outdoor unit (V, Ø, Hz)
-
380 ~ 415, 3, 50
DIMENSION
-
Indoor unit (W × H × D) (mm)
-
420 x 490 x 141
-
Outdoor unit (W × H × D) (mm)
-
1,560 x 1,019 x 520
WEIGHT
-
Indoor unit (Empty) (kg)
-
6.7
-
Outdoor unit (Empty) (kg)
-
181.0
EXTERIOR
-
Color of outdoor unit chassis (Color / RAL code)
-
Dawn gray / RAL 7037
-
Color of outdoor unit front grille (Color / RAL code)
-
Dark dawn gray / RAL 7012
-
Indoor unit (Color / RAL code)
-
Essence White / RAL 9003
REFRIGERANT
-
Type
-
R290
-
GWP
-
3
-
Precharged amount (g)
-
1,200
SOUND POWER LEVEL (OUTDOOR UNIT)
-
Rated / low noise mode (dB(A))
-
49 / 48
NOMINAL CAPACITY AND COP (A-7/W+35)
-
COP
-
3.44
-
Heating capacity (kW)
-
8.90
NOMINAL CAPACITY AND COP (A-7/W+55)
-
COP
-
2.43
-
Heating capacity (kW)
-
7.00
NOMINAL CAPACITY AND COP (A+2/W+35)
-
COP
-
3.88
-
Heating capacity (kW)
-
9.00
NOMINAL CAPACITY AND COP (A+7/W+35)
-
COP
-
4.90
-
Heating capacity (kW)
-
9.00
NOMINAL CAPACITY AND COP (A+7/W+55)
-
COP
-
3.20
-
Heating capacity (kW)
-
9.00
NOMINAL CAPACITY AND EER (A+35/W+18)
-
Cooling capacity (kW)
-
9.00
-
EER
-
3.90
NOMINAL CAPACITY AND EER (A+35/W+7)
-
Cooling capacity (kW)
-
9.00
-
EER
-
3.24
OPERATION RANGE (LEAVING WATER TEMPERATURE)
-
Cooling (Min. ~ Max.) (℃)
-
5 ~ 27
-
DHW (Min. ~ Max.) (℃)
-
15 ~ 80
-
Heating (Min. ~ Max.) (℃)
-
15 ~ 75
OPERATION RANGE (OUTDOOR AIR TEMPERATURE)
-
Cooling (Min. ~ Max.) (℃)
-
5 ~ 48
-
Heating & DHW (Min. ~ Max.) (℃)
-
-28 ~ 35
PIPING CONNECTIONS (WATER/OUTDOOR UNIT)
-
Inlet diameter (inch)
-
Male PT 1"
-
Outlet diameter (inch)
-
Male PT 1"
SEASONAL EFFICIENCY DATA (HEATING)
-
SCOP (35℃ / 55℃)
-
5.23 / 3.75
-
Seasonal space heating efficiency (ηS) (35℃ / 55℃)
-
206 / 147
-
Seasonal space heating eff. class (35℃ / 55℃)
-
A+++/A++
SOUND PRESSURE LEVEL AT 5M (OUTDOOR UNIT, CONVERT USING SWL)
-
Rated / low noise mode (dB(A))
-
27 / 26
COMPLIANCE INFORMATION
