Summary
DIMENSIONS
All Spec
CAPACITY
-
Cooling - Min / Rated / Max (kW)
-
0.9 / 6.6 / 7.42
-
Heating - Min / Rated / Max (kW)
-
0.9 / 7.5 / 8.64
-
Heating -7°C - Rated (W)
-
6000
POWER INPUT
-
Cooling - Rated (W)
-
2164
-
Heating - Rated (W)
-
2238
EER
-
EER - W/W
-
3.05
S.E.E.R.
-
S.E.E.R - W/W
-
6.90
P DESIGN C
-
P design C (kW)
-
6.6
COP
-
COP - W/W
-
3.35
S.C.O.P
-
S.C.O.P - Average / Warmer (kW)
-
4.3 / 5.3
P DESIGN H
-
P design H - Average / Warmer (kW)
-
5.0 / 2.7
ENERGY LABEL(A+++ TO D SCALE)
-
Cooling
-
A++
-
Heating - Average / Warmer
-
A+ / A+++
ANNUAL ENERGY CONSUMPTION
-
Cooling (kWh)
-
335
-
Heating - Average / Warmer (kWh)
-
1628 / 713
SOUND PRESSURE
-
Cooling - S / L / M / H dB(A)
-
31 / 34 / 42 / 47
-
Heating - L / M / H dB(A)
-
34 / 42 / 47
SOUND POWER
-
Cooling - Power dB(A)
-
65
AIR FLOW RATE
-
Cooling - S / L / M/ H (m3/min)
-
8.0 / 10.5 / 13.1 / 16.1
-
Cooling - Max (Power) (m3/min)
-
20.0
-
Heating - L / M / H (m3/min)
-
10.5 / 13.1 / 16.1
DEHUMIDIFICATION RATE
-
Dehumidification Rate (l/h)
-
2.5
RUNNING CURRENT
-
Cooling - Min / Rated / Max (A)
-
? / 9.8 / 14.0
-
Heating - Min / Rated / Max (A)
-
? / 10.4 / 14.0
STARTING CURRENT
-
Cooling / Heating - Rated (A)
-
9.8 / 10.4
POWER SUPPLY
-
Power Supply (Ø / V / Hz)
-
1/220-240/50
CIRCUIT BREAKER
-
Circuit Breaker (A)
-
25
POWER SUPPLY CABLE
-
Power Supply Cable (N x mm2)
-
3 x 2.5
POWER & TRANSMISSION CABLE
-
Power & Transmission Cable (N x mm2)
-
4 x 1.0 (Including Earth)
DIMENSION
-
Dimension (mm)
-
998 X 345 X 212
NET WEIGHT
-
Net Weight (kg)
-
13.5
FAN MOTOR OUTPUT
-
Fan Motor Output (W)
-
60
COMPLIANCE INFORMATION
