Summary
DIMENSIONS
![](/content/dam/channel/wcms/uk/images/spec/RAC-Standard-Plus-Dimention-M-N.jpg)
All Spec
CAPACITY
-
Cooling - Min / Rated / Max (kW)
-
0.89 / 3.5 / 4.04
-
Heating - Min / Rated / Max (kW)
-
0.89 / 4.0 / 5.1
-
Heating -7°C - Rated (W)
-
3000
POWER INPUT
-
Cooling - Rated (W)
-
1080
-
Heating - Rated (W)
-
1050
EER
-
EER - W/W
-
3.24
S.E.E.R.
-
S.E.E.R - W/W
-
6.6
P DESIGN C
-
P design C (kW)
-
3.5
COP
-
COP - W/W
-
3.81
S.C.O.P
-
S.C.O.P - Average / Warmer (kW)
-
4.0 / 4.9
P DESIGN H
-
P design H - Average / Warmer (kW)
-
2.5 / 1.3
ENERGY LABEL(A+++ TO D SCALE)
-
Cooling
-
A++
-
Heating - Average / Warmer
-
A+ / A++
ANNUAL ENERGY CONSUMPTION
-
Cooling (kWh)
-
186
-
Heating - Average / Warmer (kWh)
-
875 / 371
SOUND PRESSURE
-
Cooling - S / L / M / H dB(A)
-
19 / 27 / 35 / 41
-
Heating - L / M / H dB(A)
-
27 / 35 / 41
SOUND POWER
-
Cooling - Power dB(A)
-
59
AIR FLOW RATE
-
Cooling - S / L / M/ H (m3/min)
-
3.0 / 4.2 / 7.5 / 10.0
-
Cooling - Max (Power) (m3/min)
-
12.5
-
Heating - L / M / H (m3/min)
-
5.6 / 7.2 / 10.0
DEHUMIDIFICATION RATE
-
Dehumidification Rate (l/h)
-
1.3
RUNNING CURRENT
-
Cooling - Min / Rated / Max (A)
-
? / 4.7 / 6.0
-
Heating - Min / Rated / Max (A)
-
? / 4.7 / 7.0
STARTING CURRENT
-
Cooling / Heating - Rated (A)
-
4.7 / 4.7
POWER SUPPLY
-
Power Supply (Ø / V / Hz)
-
1/220-240/50
CIRCUIT BREAKER
-
Circuit Breaker (A)
-
15
POWER SUPPLY CABLE
-
Power Supply Cable (N x mm2)
-
3 x 1.0
POWER & TRANSMISSION CABLE
-
Power & Transmission Cable (N x mm2)
-
4 x 1.0 (Including Earth)
DIMENSION
-
Dimension (mm)
-
837 X 308 X 189
NET WEIGHT
-
Net Weight (kg)
-
8.7
FAN MOTOR OUTPUT
-
Fan Motor Output (W)
-
30
COMPLIANCE INFORMATION
