All Spec
POWER SUPPLY
-
#1
-
50/60 Hz 220-240 V~
COOLING CAPACITY
-
Rated (kW)
-
9
HEATING CAPACITY
-
Rated (kW)
-
9
POWER INPUT(COOLING)
-
Rated (kW)
-
0.08
POWER INPUT(HEATING)
-
Rated (kW)
-
0.08
HEAT EXCHANGER
-
Type
-
Brazed Plate HEX
-
Rated Water Flow ( LPM )
-
25.9
DIMENSION
-
Net(W x H x D) (mm)
-
490 × 850 × 315
WEIGHT
-
Net (kg)
-
42
REFRIGERANT
-
Type
-
R410A / R32
-
Control Type
-
Electronic Expansion Valve
CONNECTING PIPE
-
Liquid (mm(inch))
-
Ø 9.52(3/8)
-
Gas (mm(inch))
-
Ø 15.88(5/8)
WATER CONNECTING PIPES
-
Inlet (inch)
-
Male PT 1
-
Outlet (inch)
-
Male PT 1
SOUND POWER LEVEL
-
Cooling / Heating (dB(A))
-
44/44
SOUND PRESSURE LEVEL
-
Cooling / Heating (dB(A))
-
35/35
COMPLIANCE INFORMATION
